Order No	Product Name	Type Design	Impedance (Ohm)	Body Style	Frequency, Max (GHz)	VSWR, Max	Connector Series	Connector Gender	Connection Method	Center Contact	Cable Entry	Mount Method	Body Material	Body Plating	Captivated Type	Suitable Cables
BNC1E59-0141A/144	BNC Male RA Cable Connector for RSF141-FEP, 4GHz	Standard	50	Right Angle	4.0	N/A	BNC	Plug (Male)	Bayonet	Soldered	Soldered	None	Brass	Copper-Tin Zinc Alloy	Mechanical Captivation	RSF-141-FEP
BNC1E59-0141A/144	BNC Male RA Cable Connector for RSF141, 4GHz	Standard	50	Right Angle	4.0	N/A	BNC	Plug (Male)	Bayonet	Soldered	Soldered	None	Brass	Copper-Tin Zinc Alloy	Mechanical Captivation	Semi-Flex .141 (RSF-141)
BNC1E59-0141A/144	BNC Male RA Cable Connector for RSR141 , 4GHz	Standard	50	Right Angle	4.0	N/A	BNC	Plug (Male)	Bayonet	Soldered	Soldered	None	Brass	Copper-Tin Zinc Alloy	Mechanical Captivation	Semi-Rigid .141 (RSR-141)
BNC1E59-0141A/133	BNC Male RA Cable Connector for Belden 1673J, 4GHz	Standard	50	Right Angle	4.0	N/A	BNC	Plug (Male)	Bayonet	Soldered	Soldered	None	Brass	Nickel	Mechanical Captivation	Belden 1673J
BNC1E59-0141A/133	BNC Male RA Cable Connector for Belden 1673A, 4GHz	Standard	50	Right Angle	4.0	N/A	BNC	Plug (Male)	Bayonet	Soldered	Soldered	None	Brass	Nickel	Mechanical Captivation	Belden 1673A
BNC1E59-0141A/133	BNC Male RA Cable Connector for RG 402, 4GHz	Standard	50	Right Angle	4.0	N/A	BNC	Plug (Male)	Bayonet	Soldered	Soldered	None	Brass	Nickel	Mechanical Captivation	RG-402
BNC1E59-0141A/133	BNC Male RA Cable Connector for RSF141-PVC, 4GHz	Standard	50	Right Angle	4.0	N/A	BNC	Plug (Male)	Bayonet	Soldered	Soldered	None	Brass	Nickel	Mechanical Captivation	RSF-141-PVC
BNC1E59-0141A/133	BNC Male RA Cable Connector for RSF141-FEP, 4GHz	Standard	50	Right Angle	4.0	N/A	BNC	Plug (Male)	Bayonet	Soldered	Soldered	None	Brass	Nickel	Mechanical Captivation	RSF-141-FEP
BNC1E59-0141A/133	BNC Male RA Cable Connector for RSF141, 4GHz	Standard	50	Right Angle	4.0	N/A	BNC	Plug (Male)	Bayonet	Soldered	Soldered	None	Brass	Nickel	Mechanical Captivation	Semi-Flex .141 (RSF-141)
BNC1E59-0141A/133	BNC Male RA Cable Connector for RSR141 , 4GHz	Standard	50	Right Angle	4.0	N/A	BNC	Plug (Male)	Bayonet	Soldered	Soldered	None	Brass	Nickel	Mechanical Captivation	Semi-Rigid .141 (RSR-141)
BNC1E59-0085A/144	BNC Male RA Cable Connector, Belden 1671J, 4GHz	Standard	50	Right Angle	4.0	N/A	BNC	Plug (Male)	Bayonet	Soldered	Soldered	None	Brass	Copper-Tin Zinc Alloy	Mechanical Captivation	Belden 1671J
BNC1E59-0085A/144	BNC Male RA Cable Connector, Belden 1671A, 4GHz	Standard	50	Right Angle	4.0	N/A	BNC	Plug (Male)	Bayonet	Soldered	Soldered	None	Brass	Copper-Tin Zinc Alloy	Mechanical Captivation	Belden 1671A
BNC1E59-0085A/144	BNC Male RA Cable Connector for RG405, 4GHz	Standard	50	Right Angle	4.0	N/A	BNC	Plug (Male)	Bayonet	Soldered	Soldered	None	Brass	Copper-Tin Zinc Alloy	Mechanical Captivation	RG-405
BNC1E59-0085A/144	BNC Male RA Cable Connector, RSF086-PVC, 4GHz	Standard	50	Right Angle	4.0	N/A	BNC	Plug (Male)	Bayonet	Soldered	Soldered	None	Brass	Copper-Tin Zinc Alloy	Mechanical Captivation	RSF-086-PVC
BNC1E59-0085A/144	BNC Male RA Cable Connector, RSF086-FEP, 4GHz	Standard	50	Right Angle	4.0	N/A	BNC	Plug (Male)	Bayonet	Soldered	Soldered	None	Brass	Copper-Tin Zinc Alloy	Mechanical Captivation	RSF-086-FEP
BNC1E59-0085A/144	BNC Male RA Cable Connector, .086, RSF086, 4GHz	Standard	50	Right Angle	4.0	N/A	BNC	Plug (Male)	Bayonet	Soldered	Soldered	None	Brass	Copper-Tin Zinc Alloy	Mechanical Captivation	Semi-Flex .086 (RSF-086)
BNC1E59-0085A/144	BNC Male RA Cable Connector, .086, RSR086, 4GHz	Standard	50	Right Angle	4.0	N/A	BNC	Plug (Male)	Bayonet	Soldered	Soldered	None	Brass	Copper-Tin Zinc Alloy	Mechanical Captivation	Semi-Rigid .086 (RSR-086)
BNC1E59-0085A/133	BNC Male RA Cable Connector, Belden 1671J, 4GHz	Standard	50	Right Angle	4.0	N/A	BNC	Plug (Male)	Bayonet	Soldered	Soldered	None	Brass	Nickel	Mechanical Captivation	Belden 1671J
BNC1E59-0085A/133	BNC Male RA Cable Connector, Belden 1671A, 4GHz	Standard	50	Right Angle	4.0	N/A	BNC	Plug (Male)	Bayonet	Soldered	Soldered	None	Brass	Nickel	Mechanical Captivation	Belden 1671A
BNC1E59-0085A/133	BNC Male RA Cable Connector for RG405, 4GHz	Standard	50	Right Angle	4.0	N/A	BNC	Plug (Male)	Bayonet	Soldered	Soldered	None	Brass	Nickel	Mechanical Captivation	RG-405
BNC1E59-0085A/133	BNC Male RA Cable Connector, RSF086-PVC, 4GHz	Standard	50	Right Angle	4.0	N/A	BNC	Plug (Male)	Bayonet	Soldered	Soldered	None	Brass	Nickel	Mechanical Captivation	RSF-086-PVC
BNC1E59-0085A/133	BNC Male RA Cable Connector, RSF086-FEP, 4GHz	Standard	50	Right Angle	4.0	N/A	BNC	Plug (Male)	Bayonet	Soldered	Soldered	None	Brass	Nickel	Mechanical Captivation	RSF-086-FEP
BNC1E59-0085A/133	BNC Male RA Cable Connector, .086, RSF086, 4GHz	Standard	50	Right Angle	4.0	N/A	BNC	Plug (Male)	Bayonet	Soldered	Soldered	None	Brass	Nickel	Mechanical Captivation	Semi-Flex .086 (RSF-086)
BNC1E59-0085A/133	BNC Male RA Cable Connector, .086, RSR086, 4GHz	Standard	50	Right Angle	4.0	N/A	BNC	Plug (Male)	Bayonet	Soldered	Soldered	None	Brass	Nickel	Mechanical Captivation	Semi-Rigid .086 (RSR-086)
