Cable Connectors - ROSNOL RF / Microwave

Order No	Product Name	Type Design	Impedance (Ohm)	Body Style	Frequency, Max (GHz)	VSWR, Max	Connector Series	Connector Gender	Connection Method	Center Contact	Cable Entry	Mount Method	Body Material	Body Plating	Captivated Type	Suitable Cables
BNC2CA50-G058A/H3	BNC Female Bulkhead Cable Connector, RG58, 4 GHz	Standard	50	Straight	4.0	1.20	BNC	Jack (Female)	Bayonet	Soldered	Crimped	Bulkhead	Brass	Nickel	Mechanical Captivation	RG-58
BNC2C50-R400A/H4	BNC Female Cable Connector for Belden 9913, 4GHz	Standard	50	Straight	4.0	N/A	BNC	Jack (Female)	Bayonet	Crimped or Soldered	Crimped	None	Brass	Copper-Tin Zinc Alloy	Mechanical Captivation	Belden 9913
BNC2C50-R400A/H4	BNC Female Cable Connector for Belden 8214, 4GHz	Standard	50	Straight	4.0	N/A	BNC	Jack (Female)	Bayonet	Crimped or Soldered	Crimped	None	Brass	Copper-Tin Zinc Alloy	Mechanical Captivation	Belden 8214
BNC2C50-R400A/H4	BNC Female Cable Connector for Belden 7810A, 4GHz	Standard	50	Straight	4.0	N/A	BNC	Jack (Female)	Bayonet	Crimped or Soldered	Crimped	None	Brass	Copper-Tin Zinc Alloy	Mechanical Captivation	Belden 7810A
BNC2C50-R400A/H4	BNC Female Cable Connector for LMR 400, 4GHz	Standard	50	Straight	4.0	N/A	BNC	Jack (Female)	Bayonet	Crimped or Soldered	Crimped	None	Brass	Copper-Tin Zinc Alloy	Mechanical Captivation	LMR-400
BNC2C50-R400A/H3	BNC Female Cable Connector for Belden 9913, 4GHz	Standard	50	Straight	4.0	N/A	BNC	Jack (Female)	Bayonet	Crimped or Soldered	Crimped	None	Brass	Nickel	Mechanical Captivation	Belden 9913
BNC2C50-R400A/H3	BNC Female Cable Connector for Belden 8214, 4GHz	Standard	50	Straight	4.0	N/A	BNC	Jack (Female)	Bayonet	Crimped or Soldered	Crimped	None	Brass	Nickel	Mechanical Captivation	Belden 8214
BNC2C50-R400A/H3	BNC Female Cable Connector for Belden 7810A, 4GHz	Standard	50	Straight	4.0	N/A	BNC	Jack (Female)	Bayonet	Crimped or Soldered	Crimped	None	Brass	Nickel	Mechanical Captivation	Belden 7810A
BNC2C50-R400A/H3	BNC Female Cable Connector for LMR 400, 4GHz	Standard	50	Straight	4.0	N/A	BNC	Jack (Female)	Bayonet	Crimped or Soldered	Crimped	None	Brass	Nickel	Mechanical Captivation	LMR-400
BNC2C50-G213A/H4	BNC Female Cable Connector for RG 213, 4GHz	Standard	50	Straight	4.0	1.20	BNC	Jack (Female)	Threaded (Screw-lock)	Crimped or Soldered	Crimped	None	Brass	Copper-Tin Zinc Alloy	Mechanical Captivation	RG-213
BNC2C50-G142A/H4	BNC Female Cable Connector for RG 400, 4GHz	Standard	50	Straight	4.0	1.12	BNC	Jack (Female)	Bayonet	Crimped or Soldered	Crimped	None	Brass	Copper-Tin Zinc Alloy	Mechanical Captivation	RG-400
BNC2C50-G142A/H4	BNC Female Cable Connector for RG 223, 4GHz	Standard	50	Straight	4.0	1.12	BNC	Jack (Female)	Bayonet	Crimped or Soldered	Crimped	None	Brass	Copper-Tin Zinc Alloy	Mechanical Captivation	RG-223
BNC2C50-G142A/H4	BNC Female Cable Connector for RG 55, 4GHz	Standard	50	Straight	4.0	1.12	BNC	Jack (Female)	Bayonet	Crimped or Soldered	Crimped	None	Brass	Copper-Tin Zinc Alloy	Mechanical Captivation	RG-55
BNC2C50-G142A/H4	BNC Female Cable Connector for RG 142, 4GHz	Standard	50	Straight	4.0	1.12	BNC	Jack (Female)	Bayonet	Crimped or Soldered	Crimped	None	Brass	Copper-Tin Zinc Alloy	Mechanical Captivation	RG-142
BNC2C50-G142A/H3	BNC Female Cable Connector for RG 400, 4GHz	Standard	50	Straight	4.0	1.12	BNC	Jack (Female)	Bayonet	Crimped or Soldered	Crimped	None	Brass	Nickel	Mechanical Captivation	RG-400
BNC2C50-G142A/H3	BNC Female Cable Connector for RG 223, 4GHz	Standard	50	Straight	4.0	1.12	BNC	Jack (Female)	Bayonet	Crimped or Soldered	Crimped	None	Brass	Nickel	Mechanical Captivation	RG-223
BNC2C50-G142A/H3	BNC Female Cable Connector for RG 55, 4GHz	Standard	50	Straight	4.0	1.12	BNC	Jack (Female)	Bayonet	Crimped or Soldered	Crimped	None	Brass	Nickel	Mechanical Captivation	RG-55
BNC2C50-G142A/H3	BNC Female Cable Connector for RG 142, 4GHz	Standard	50	Straight	4.0	1.12	BNC	Jack (Female)	Bayonet	Crimped or Soldered	Crimped	None	Brass	Nickel	Mechanical Captivation	RG-142
BNC2C50-D316A/H3	BNC Female Cable Connector for RG 188, 6GHz	Standard	50	Straight	6.0	1.22	BNC	Jack (Female)	Bayonet	Crimped	Crimped	None	Brass	Nickel	Mechanical Captivation	RG-188
BNC2C50-D316A/H3	BNC Female Cable Connector for RG 316D, 6GHz	Standard	50	Straight	6.0	1.22	BNC	Jack (Female)	Bayonet	Crimped	Crimped	None	Brass	Nickel	Mechanical Captivation	RG-316D
BNC1E59-0141A/144	BNC Male RA Cable Connector for Belden 1673J, 4GHz	Standard	50	Right Angle	4.0	N/A	BNC	Plug (Male)	Bayonet	Soldered	Soldered	None	Brass	Copper-Tin Zinc Alloy	Mechanical Captivation	Belden 1673J
BNC1E59-0141A/144	BNC Male RA Cable Connector for Belden 1673A, 4GHz	Standard	50	Right Angle	4.0	N/A	BNC	Plug (Male)	Bayonet	Soldered	Soldered	None	Brass	Copper-Tin Zinc Alloy	Mechanical Captivation	Belden 1673A
BNC1E59-0141A/144	BNC Male RA Cable Connector for RG 402, 4GHz	Standard	50	Right Angle	4.0	N/A	BNC	Plug (Male)	Bayonet	Soldered	Soldered	None	Brass	Copper-Tin Zinc Alloy	Mechanical Captivation	RG-402
BNC1E59-0141A/144	BNC Male RA Cable Connector for RSF141-PVC, 4GHz	Standard	50	Right Angle	4.0	N/A	BNC	Plug (Male)	Bayonet	Soldered	Soldered	None	Brass	Copper-Tin Zinc Alloy	Mechanical Captivation	RSF-141-PVC
