Key Specifications
Description
SMC Male to FME Male Straight Adapter, DC-2 GHz, VSWR ≤ 1.20, 50 Ω Impedance.
ROSNOL AD-MC1E15A/H44-H4 is a precision RF adapter featuring an SMC Plug (Male) to FME Plug (Male) configuration. Designed for 50 Ω systems, it operates from DC to 2 GHz with VSWR ≤ 1.20 and low insertion loss, providing reliable interconnection for RF communication equipment, wireless networks, antenna assemblies, and signal transmission applications.
The adapter is constructed with beryllium copper center contacts that utilize gold plating over non-magnetic nickel-phosphorus underplating for excellent conductivity and long-term contact reliability. Both connector bodies are manufactured from brass with copper-tin-zinc alloy plating for enhanced durability and corrosion resistance, while PTFE insulators ensure stable dielectric performance. Technical characteristics include insertion loss ≤ 0.01 × √F (GHz) dB and low contact resistance for efficient RF signal transfer.
With screw-lock coupling interfaces, minimum 500 mating cycles on the SMC side, and an operating temperature range of -65°C to +165°C, this adapter is engineered for dependable operation in demanding RF environments. It is ideal for wireless infrastructure, communication systems, test instrumentation, and antenna-related applications requiring secure SMC-to-FME connectivity.
