Order No	Product Name	Type Design	Impedance (Ohm)	Body Style	Frequency, Max (GHz)	VSWR, Max	Connector Style	Connector Series	Connector Gender	Connection Method	Mount Method	Body Material	Body Plating	Captivated Type	Bankend Type
PCA2BT50-0012A/9X	Precision SMA Jack (Female) Straight Field Replaceable Connector 2 Hole Flange, 12.22mm (.481 inch) DC-27GHz VSWR1.15	Precision	50	Straight	27	1.15	Field Replaceable	Precision SMA	Jack (Female)	Threaded (Screw-lock)	2 Hole Flange	Stainless Steel	Passivated	Mechanical Captivation	Accepts Pin ∅0.30 [.012]
PCA2BT50-0009C/9X	Precision SMA Jack (Female) Straight Field Replaceable Connector 2 Hole Flange, 9.02mm (.355 inch) DC-27GHz VSWR1.15	Precision	50	Straight	27	1.15	Field Replaceable	Precision SMA	Jack (Female)	Threaded (Screw-lock)	2 Hole Flange	Stainless Steel	Passivated	Mechanical Captivation	Accepts Pin ∅0.23 [.009]
PCA2BT50-0009A/9X	Precision SMA Jack (Female) Straight Field Replaceable Connector 2 Hole Flange, 12.22mm (.481 inch) DC-27GHz VSWR1.15	Precision	50	Straight	27	1.15	Field Replaceable	Precision SMA	Jack (Female)	Threaded (Screw-lock)	2 Hole Flange	Stainless Steel	Passivated	Mechanical Captivation	Accepts Pin ∅0.23 [.009]
PCA2BF50-0036B/9X	Precision SMA Jack (Female) Straight Field Replaceable Connector 4 Hole Flange, 6.35mm (.250 inch) DC-27GHz VSWR1.15	Precision	50	Straight	27	1.15	Field Replaceable	Precision SMA	Jack (Female)	Threaded (Screw-lock)	4 Hole Flange	Stainless Steel	Passivated	Mechanical Captivation	Accepts Pin ∅0.91 [.036]
PCA2BF50-0020B/9X	Precision SMA Jack (Female) Straight Field Replaceable Connector 4 Hole Flange, 6.35mm (.250 inch) DC-27GHz VSWR1.15	Precision	50	Straight	27	1.15	Field Replaceable	Precision SMA	Jack (Female)	Threaded (Screw-lock)	4 Hole Flange	Stainless Steel	Passivated	Mechanical Captivation	Accepts Pin ∅0.51 [.020]
PCA2BF50-0018B/9X	Precision SMA Jack (Female) Straight Field Replaceable Connector 4 Hole Flange, 6.35mm (.250 inch) DC-27GHz VSWR1.15	Precision	50	Straight	27	1.15	Field Replaceable	Precision SMA	Jack (Female)	Threaded (Screw-lock)	4 Hole Flange	Stainless Steel	Passivated	Mechanical Captivation	Accepts Pin ∅0.46 [.018]
PCA2BF50-0015B/9X	Precision SMA Jack (Female) Straight Field Replaceable Connector 4 Hole Flange, 6.35mm (.250 inch) DC-27GHz VSWR1.15	Precision	50	Straight	27	1.15	Field Replaceable	Precision SMA	Jack (Female)	Threaded (Screw-lock)	4 Hole Flange	Stainless Steel	Passivated	Mechanical Captivation	Accepts Pin ∅0.38 [.015]
PCA2BF50-0012B/9X	Precision SMA Jack (Female) Straight Field Replaceable Connector 4 Hole Flange, 6.35mm (.250 inch) DC-27GHz VSWR1.15	Precision	50	Straight	27	1.15	Field Replaceable	Precision SMA	Jack (Female)	Threaded (Screw-lock)	4 Hole Flange	Stainless Steel	Passivated	Mechanical Captivation	Accepts Pin ∅0.30 [.012]
PCA2BF50-0009B/9X	Precision SMA Jack (Female) Straight Field Replaceable Connector 4 Hole Flange, 6.35mm (.250 inch) DC-27GHz VSWR1.15	Precision	50	Straight	27	1.15	Field Replaceable	Precision SMA	Jack (Female)	Threaded (Screw-lock)	4 Hole Flange	Stainless Steel	Passivated	Mechanical Captivation	Accepts Pin ∅0.23 [.009]
PCA2BF50-0036A/9X	Precision SMA Jack (Female) Straight Field Replaceable Connector 4 Hole Flange, 8.64mm (.340 inch) DC-27GHz VSWR1.15	Precision	50	Straight	27	1.15	Field Replaceable	Precision SMA	Jack (Female)	Threaded (Screw-lock)	4 Hole Flange	Stainless Steel	Passivated	Mechanical Captivation	Accepts Pin ∅0.91 [.036]
PCA2BF50-0020A/9X	Precision SMA Jack (Female) Straight Field Replaceable Connector 4 Hole Flange, 8.64mm (.340 inch) DC-27GHz VSWR1.15	Precision	50	Straight	27	1.15	Field Replaceable	Precision SMA	Jack (Female)	Threaded (Screw-lock)	4 Hole Flange	Stainless Steel	Passivated	Mechanical Captivation	Accepts Pin ∅0.51 [.020]
PCA2BF50-0018A/9X	Precision SMA Jack (Female) Straight Field Replaceable Connector 4 Hole Flange, 8.64mm (.340 inch) DC-27GHz VSWR1.15	Precision	50	Straight	27	1.15	Field Replaceable	Precision SMA	Jack (Female)	Threaded (Screw-lock)	4 Hole Flange	Stainless Steel	Passivated	Mechanical Captivation	Accepts Pin ∅0.46 [.018]
PCA2BF50-0015A/9X	Precision SMA Jack (Female) Straight Field Replaceable Connector 4 Hole Flange, 8.64mm (.340 inch) DC-27GHz VSWR1.15	Precision	50	Straight	27	1.15	Field Replaceable	Precision SMA	Jack (Female)	Threaded (Screw-lock)	4 Hole Flange	Stainless Steel	Passivated	Mechanical Captivation	Accepts Pin ∅0.38 [.015]
PCA2BF50-0012A/9X	Precision SMA Jack (Female) Straight Field Replaceable Connector 4 Hole Flange, 8.64mm (.340 inch) DC-27GHz VSWR1.15	Precision	50	Straight	27	1.15	Field Replaceable	Precision SMA	Jack (Female)	Threaded (Screw-lock)	4 Hole Flange	Stainless Steel	Passivated	Mechanical Captivation	Accepts Pin ∅0.30 [.012]
PCA2BF50-0009A/9X	Precision SMA Jack (Female) Straight Field Replaceable Connector 4 Hole Flange, 8.64mm (.340 inch) DC-27GHz VSWR1.15	Precision	50	Straight	27	1.15	Field Replaceable	Precision SMA	Jack (Female)	Threaded (Screw-lock)	4 Hole Flange	Stainless Steel	Passivated	Mechanical Captivation	Accepts Pin ∅0.23 [.009]
PCA1BT50-0020A-EMI/9XX	Precision SMA Plug (Male) Straight Field Replaceable Connector 2 Hole Flange, 12.22mm (.481 inch) DC-27GHz VSWR1.15	Precision	50	Straight	27	1.15	Field Replaceable	Precision SMA	Plug (Male)	Threaded (Screw-lock)	2 Hole Flange	Stainless Steel	Passivated	Mechanical Captivation	Accepts Pin ∅0.51 [.020]
PC2BF50-0036A/9X	3.5mm Plug (Male) Straight Field Replaceable Connector 4 Hole Flange, 8.64mm (.326.5 inch) DC-26.5GHz VSWR1.15	Precision	50	Straight	26.5	1.15	Field Replaceable	3.5mm	Jack (Female)	Threaded (Screw-lock)	4 Hole Flange	Stainless Steel	Passivated	Mechanical Captivation	Accepts Pin ∅0.91 [.036]
PC2BF50-0020A/9X	3.5mm Jack (Female) Straight Field Replaceable Connector 4 Hole Flange, 8.64mm (.326.5 inch) DC-26.5GHz VSWR1.15	Precision	50	Straight	26.5	1.15	Field Replaceable	3.5mm	Jack (Female)	Threaded (Screw-lock)	4 Hole Flange	Stainless Steel	Passivated	Mechanical Captivation	Accepts Pin ∅0.51 [.020]
PC2BF50-0018A/9X	3.5mm Jack (Female) Straight Field Replaceable Connector 4 Hole Flange, 8.64mm (.326.5 inch) DC-26.5GHz VSWR1.15	Precision	50	Straight	26.5	1.15	Field Replaceable	3.5mm	Jack (Female)	Threaded (Screw-lock)	4 Hole Flange	Stainless Steel	Passivated	Mechanical Captivation	Accepts Pin ∅0.46 [.018]
PC2BF50-0015A/9X	3.5mm Jack (Female) Straight Field Replaceable Connector 4 Hole Flange, 8.64mm (.326.5 inch) DC-26.5GHz VSWR1.15	Precision	50	Straight	26.5	1.15	Field Replaceable	3.5mm	Jack (Female)	Threaded (Screw-lock)	4 Hole Flange	Stainless Steel	Passivated	Mechanical Captivation	Accepts Pin ∅0.38 [.015]
PC2BF50-0012A/9X	3.5mm Jack (Female) Straight Field Replaceable Connector 4 Hole Flange, 8.64mm (.326.5 inch) DC-26.5GHz VSWR1.15	Precision	50	Straight	26.5	1.15	Field Replaceable	3.5mm	Jack (Female)	Threaded (Screw-lock)	4 Hole Flange	Stainless Steel	Passivated	Mechanical Captivation	Accepts Pin ∅0.30 [.012]
PC2BF50-0009A/9X	3.5mm Jack (Female) Straight Field Replaceable Connector 4 Hole Flange, 8.64mm (.326.5 inch) DC-26.5GHz VSWR1.15	Precision	50	Straight	26.5	1.15	Field Replaceable	3.5mm	Jack (Female)	Threaded (Screw-lock)	4 Hole Flange	Stainless Steel	Passivated	Mechanical Captivation	Accepts Pin ∅0.23 [.009]
PC1BF50-0036A/9XX	3.5mm Plug (Male) Straight Field Replaceable Connector 4 Hole Flange, 8.64mm (.326.5 inch) DC-26.5GHz VSWR1.15	Precision	50	Straight	26.5	1.15	Field Replaceable	3.5mm	Plug (Male)	Threaded (Screw-lock)	4 Hole Flange	Stainless Steel	Passivated	Mechanical Captivation	Accepts Pin ∅0.91 [.036]
PC1BF50-0020A/9XX	3.5mm Plug (Male) Straight Field Replaceable Connector 4 Hole Flange, 8.64mm (.326.5 inch) DC-26.5GHz VSWR1.15	Precision	50	Straight	26.5	1.15	Field Replaceable	3.5mm	Plug (Male)	Threaded (Screw-lock)	4 Hole Flange	Stainless Steel	Passivated	Mechanical Captivation	Accepts Pin ∅0.51 [.020]
