Order No	Product Name	Type Design	Connection Type	Connector 1 Series	Connector 1 Gender	Connector 2 Series	Connector 2 Gender	Impedance (Ohm)	Body Style	Panel Mount	Connector 1 Connection Method	Connector 2 Connection Method	Frequency, Max (GHz)	Connector 1 Body Material	Connector 1 Body Plating	Connector 2 Body Material	Connector 2 Body Plating	VSWR, Max
AD-A2BC25A-PT/9X-9X	SMA Jack (Female) to BMC Jack (Female) 2 Hole Panel Adapter, DC-1GHz	Standard	Between Series	SMA	Jack (Female)	BMC	Jack (Female)	50	Straight	2 Hole Flange	Snap-On	Slide-On	1.0	Stainless Steel	Passivated	Stainless Steel	Passivated	N/A
AD-A2BA25D-PT/9X-9X	SMA Jack (Female) to BMA Jack (Female) 2 Hole Panel Adapter, DC-18GHz VSWR 1.25	Standard	Between Series	SMA	Jack (Female)	BMA	Jack (Female)	50	Straight	2 Hole Flange	Slide-On	Threaded (Screw-lock)	18	Stainless Steel	Passivated	Stainless Steel	Passivated	1.20
AD-A2BA25D-PT/9X-9X	SMA Jack (Female) to BMA Jack (Female) 2 Hole Panel Adapter, DC-18GHz VSWR 1.25	Standard	Between Series	SMA	Jack (Female)	BMA	Jack (Female)	50	Straight	2 Hole Flange	Threaded (Screw-lock)	Slide-On	18	Stainless Steel	Passivated	Stainless Steel	Passivated	1.20
AD-A2BA25C-PT/9X-9X	SMA Jack (Female) to BMA Jack (Female) 2 Hole Panel Adapter, DC-18GHz VSWR 1.25	Standard	Between Series	BMA	Jack (Female)	SMA	Jack (Female)	50	Straight	2 Hole Flange	Slide-On	Threaded (Screw-lock)	18	Stainless Steel	Passivated	Stainless Steel	Passivated	1.25
AD-A2BA25C-PT/9X-9X	SMA Jack (Female) to BMA Jack (Female) 2 Hole Panel Adapter, DC-18GHz VSWR 1.25	Standard	Between Series	SMA	Jack (Female)	BMA	Jack (Female)	50	Straight	2 Hole Flange	Threaded (Screw-lock)	Slide-On	18	Stainless Steel	Passivated	Stainless Steel	Passivated	1.25
AD-A2BA25B-PT/9X-9XX	SMA Jack (Female) to BMA Jack (Female) 2 Hole Panel Adapter, DC-18GHz VSWR 1.25	Standard	Between Series	BMA	Jack (Female)	SMA	Jack (Female)	50	Straight	2 Hole Flange	Slide-On	Threaded (Screw-lock)	18	Stainless Steel	Passivated	Stainless Steel	Passivated	1.25
AD-A2BA25B-PT/9X-9XX	SMA Jack (Female) to BMA Jack (Female) 2 Hole Panel Adapter, DC-18GHz VSWR 1.25	Standard	Between Series	SMA	Jack (Female)	BMA	Jack (Female)	50	Straight	2 Hole Flange	Threaded (Screw-lock)	Slide-On	18	Stainless Steel	Passivated	Stainless Steel	Passivated	1.25
AD-A2BA25A-PT-AGT/91X-91	SMA Jack (Female) to BMA Jack (Female) 2 Hole Panel Adapter, DC-18GHz VSWR 1.25	Standard	Between Series	BMA	Jack (Female)	SMA	Jack (Female)	50	Straight	2 Hole Flange	Slide-On	Threaded (Screw-lock)	18	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	1.25
AD-A2BA25A-PT-AGT/91X-91	SMA Jack (Female) to BMA Jack (Female) 2 Hole Panel Adapter, DC-18GHz VSWR 1.25	Standard	Between Series	SMA	Jack (Female)	BMA	Jack (Female)	50	Straight	2 Hole Flange	Threaded (Screw-lock)	Slide-On	18	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	1.25
AD-A2BA25A-PT/9X-9XX	SMA Jack (Female) to BMA Jack (Female) 2 Hole Panel Adapter, DC-18GHz VSWR 1.25	Standard	Between Series	BMA	Jack (Female)	SMA	Jack (Female)	50	Straight	2 Hole Flange	Slide-On	Threaded (Screw-lock)	18	Stainless Steel	Passivated	Stainless Steel	Passivated	1.25
AD-A2BA25A-PT/9X-9XX	SMA Jack (Female) to BMA Jack (Female) 2 Hole Panel Adapter, DC-18GHz VSWR 1.25	Standard	Between Series	SMA	Jack (Female)	BMA	Jack (Female)	50	Straight	2 Hole Flange	Threaded (Screw-lock)	Slide-On	18	Stainless Steel	Passivated	Stainless Steel	Passivated	1.25
AD-A2BA25A-PT/91X-91	SMA Jack (Female) to BMA Jack (Female) 2 Hole Panel Adapter, DC-18GHz VSWR 1.25	Standard	Between Series	SMA	Jack (Female)	BMA	Jack (Female)	50	Straight	2 Hole Flange	Slide-On	Threaded (Screw-lock)	18	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	1.25
AD-A2BA25A-PT/91X-91	SMA Jack (Female) to BMA Jack (Female) 2 Hole Panel Adapter, DC-18GHz VSWR 1.25	Standard	Between Series	SMA	Jack (Female)	BMA	Jack (Female)	50	Straight	2 Hole Flange	Threaded (Screw-lock)	Slide-On	18	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	1.25
AD-A2BA25A/1X-1X	SMA Jack (Female) to BMA Jack (Female) Adapter, DC-22GHz VSWR1.30	Standard	Between Series	BMA	Jack (Female)	SMA	Jack (Female)	50	Straight	None	Slide-On	Threaded (Screw-lock)	22	Stainless Steel	Passivated	Stainless Steel	Passivated	1.30
AD-A2BA25A/1X-1X	SMA Jack (Female) to BMA Jack (Female) Adapter, DC-22GHz VSWR1.30	Standard	Between Series	SMA	Jack (Female)	BMA	Jack (Female)	50	Straight	None	Threaded (Screw-lock)	Slide-On	22	Stainless Steel	Passivated	Stainless Steel	Passivated	1.30
AD-A2B25A-PF/9X-9X	SMA Jack (Female) to BNC Jack (Female) 4 Hole Panel Adapter, DC-4GHz VSWR1.20	Standard	Between Series	BNC	Jack (Female)	SMA	Jack (Female)	50	Straight	4 Hole Flange	Bayonet	Threaded (Screw-lock)	4.0	Stainless Steel	Passivated	Stainless Steel	Passivated	1.20
AD-A2B25A-PF/9X-9X	SMA Jack (Female) to BNC Jack (Female) 4 Hole Panel Adapter, DC-4GHz VSWR1.20	Standard	Between Series	SMA	Jack (Female)	BNC	Jack (Female)	50	Straight	4 Hole Flange	Threaded (Screw-lock)	Bayonet	4.0	Stainless Steel	Passivated	Stainless Steel	Passivated	1.20
AD-A2B25A-PF/9X-93	SMA Jack (Female) to BNC Jack (Female) 4 Hole Panel Adapter, DC-4GHz VSWR1.20	Standard	Between Series	SMA	Jack (Female)	BNC	Jack (Female)	50	Straight	4 Hole Flange	Threaded (Screw-lock)	Bayonet	4.0	Stainless Steel	Passivated	Brass	Nickel	1.20
AD-A2B25A-PF/9X-93	SMA Jack (Female) to BNC Jack (Female) 4 Hole Panel Adapter, DC-4GHz VSWR1.20	Standard	Between Series	SMA	Jack (Female)	BNC	Jack (Female)	50	Straight	4 Hole Flange	Threaded (Screw-lock)	Bayonet	4.0	Stainless Steel	Passivated	Brass	Nickel	1.20
AD-A2B25A-PF/91-93	SMA Jack (Female) to BNC Jack (Female) 4 Hole Panel Adapter, DC-4GHz VSWR1.20	Standard	Between Series	BNC	Jack (Female)	SMA	Jack (Female)	50	Straight	4 Hole Flange	Bayonet	Threaded (Screw-lock)	4.0	Brass	Nickel	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	1.20
AD-A2B25A/9X-9X	SMA Jack (Female) to BNC Jack (Female) Adpter, DC-6GHz VSWR1.20	Standard	Between Series	BNC	Jack (Female)	SMA	Jack (Female)	50	Straight	None	Bayonet	Threaded (Screw-lock)	6.0	Stainless Steel	Passivated	Stainless Steel	Passivated	1.20
AD-A2431025A-BH/94-94	SMA Jack (Female) to 4.3-10 Jack (Female) Bulkhead Adapter, DC-12GHz VSWR 1.15	Standard	Between Series	4.3-10	Jack (Female)	SMA	Jack (Female)	50	Straight	Bulkhead	Threaded (Screw-lock)	Threaded (Screw-lock)	12	Brass	Copper-Tin-Zinc Alloy	Brass	Copper-Tin-Zinc Alloy	1.15
AD-PCT1A25C/9XX-9X	Precision TNC Plug (Male) to SMA Jack (Female) Adapter, DC-18GHz VSWR 1.20	Precision	Between Series	Precision TNC	Plug (Male)	SMA	Jack (Female)	50	Straight	None	Threaded (Screw-lock)	Threaded (Screw-lock)	18	Stainless Steel	Passivated	Stainless Steel	Passivated	1.20
AD-PCT1A25C/9XX-9X	Precision TNC Plug (Male) to SMA Jack (Female) Adapter, DC-18GHz VSWR 1.20	Precision	Between Series	SMA	Jack (Female)	Precision TNC	Plug (Male)	50	Straight	None	Threaded (Screw-lock)	Threaded (Screw-lock)	18	Stainless Steel	Passivated	Stainless Steel	Passivated	1.20
