N Plug (Male) Right-Angle Cable Connector for LMR 400, RNL-400, BELDEN 7810A, BELDEN 8214, BELDEN 9913, DC - 8GHz VSWR 1.30
Key Specifications
Type Design:
Standard
Body Style:
Right Angle
Impedance (Ohm):
50
Frequency, Max (GHz):
8.0
VSWR, Max:
1.30
Connector Style:
Cable Connector
Connector Series:
N
Connector Gender:
Plug (Male)
Connection Method:
Threaded (Screw-lock)
Center Contact:
Plug-in
Cable Entry:
Crimped
Mount Method:
None
Body Material:
Brass
Body Plating:
Copper-Tin Zinc Alloy
Captivated Type:
Mechanical Captivation
Suitable Cables:
LMR-400
Description
N Cable Plug (Male) | Crimped Cable Entry | Screw-lock | Brass Body
The ROSNOL N1C59-EZR400A/944 is a high-performance N-type cable plug designed for crimped cable entry and screw-lock coupling. Compatible with Times Microwave LMR400, ROSNOL RNL400, and Belden-7810A, Belden-8214, Belden-9913 cables, it supports frequencies up to 8 GHz with VSWR ≤ 1.30 and insertion loss ≤ 0.05 × √F (GHz) dB, ensuring stable signal transmission in demanding RF environments.The ROSNOL N1C59-EZR400A/944 features a beryllium copper center contact with gold plating over nickel, a brass body plated with copper-tin-zinc alloy, and a PTFE insulator. The coupling nut and crimp ferrules are also brass with copper-tin-zinc alloy plating. A silicone rubber gasket ensures environmental sealing, and the connector operates reliably across a temperature range of -65°C to +165°C.
ROSNOL’s precision-engineered RF connectors offer a competitive alternative to products from leading manufacturers in Europe, the USA, and other global markets. All Rosnol RF components are precision-manufactured in ISO 9001-certified facilities, and are fully RoHS and REACH compliant, ensuring environmental safety and global regulatory alignment. Customization services for plating, materials, and mechanical design are available upon request.
