N Jack (Female) Straight Cable Connector for LMR 400, RNL-400, BELDEN 7810A, BELDEN 8214, BELDEN 9913, DC - 8GHz VSWR 1.25
Key Specifications
Type Design:
Standard
Body Style:
Straight
Impedance (Ohm):
50
Frequency, Max (GHz):
8.0
VSWR, Max:
1.25
Connector Series:
N
Connector Gender:
Jack (Female)
Connection Method:
Threaded (Screw-lock)
Center Contact:
Plug-in
Cable Entry:
Crimped
Mount Method:
None
Body Material:
Brass
Body Plating:
Copper-Tin Zinc Alloy
Captivated Type:
Mechanical Captivation
Suitable Cables:
LMR-400
Description
N Jack (Female) | Crimped Cable Entry | Screw-lock | Brass Body
The ROSNOL N2C50-EZR400A/H4 is a robust N Jack (Female) connector engineered for 50Ω systems, operating from DC to 8 GHz with VSWR ≤ 1.25 (≥ 19.08 dB) and insertion loss ≤ 0.05 × √F(GHz) dB. It features a screw-lock coupling mechanism and plug-in center contact, with crimped cable entry for secure and efficient termination.The connector body and crimp ferrules are brass plated with Copper-Tin-Zinc alloy. The center contact is phosphor bronze with gold plating over a nickel underlayer. PTFE is used for insulation, ensuring stable dielectric properties. Compatible with Times LMR 400, ROSNOL RNL 400, BELDEN 7810A, BELDEN 8214, and BELDEN 9913 cables.
ROSNOL’s precision-engineered RF connectors offer a competitive alternative to products from leading manufacturers in Europe, the USA, and other global markets. All Rosnol RF components are precision-manufactured in ISO 9001-certified facilities, and are fully RoHS and REACH compliant, ensuring environmental safety and global regulatory alignment. Customization services for plating, materials, and mechanical design are available upon request.
