N Jack (Female) Straight Cable Connector for LMR 400, RNL-400, BELDEN 7810A, BELDEN 8214, BELDEN 9913, DC - 8GHz VSWR 1.25
Key Specifications
Type Design:
Standard
Body Style:
Straight
Impedance (Ohm):
50
Frequency, Max (GHz):
8.0
VSWR, Max:
1.25
Connector Style:
Cable Connector
Connector Series:
N
Connector Gender:
Jack (Female)
Connection Method:
Threaded (Screw-lock)
Center Contact:
Plug-in
Cable Entry:
Crimped
Mount Method:
None
Body Material:
Brass
Body Plating:
Nickel
Captivated Type:
Mechanical Captivation
Suitable Cables:
LMR-400
Description
N Jack (Female) | Crimped Cable Entry | Screw-lock | Brass Body
The ROSNOL N2C50-EZR400A/13 is a high-performance N Jack (Female) connector designed for 50Ω impedance systems, supporting frequencies from DC to 8 GHz with a maximum VSWR of 1.25 (≥ 19.08 dB) and insertion loss ≤ 0.05 × √F(GHz) dB. Featuring a screw-lock coupling mechanism and plug-in center contact, this connector ensures secure mating and stable signal transmission. Cable entry is crimped for reliable mechanical retention.The body and crimp ferrules are made of brass with nickel plating, while the center contact is brass with gold plating over a nickel underlayer. The insulator is PTFE, ensuring excellent dielectric performance. Compatible cables include Times LMR400, ROSNOL RNL400, BELDEN 7810A, BELDEN 8214, and BELDEN 9913.
ROSNOL’s precision-engineered RF connectors offer a competitive alternative to products from leading manufacturers in Europe, the USA, and other global markets. All Rosnol RF components are precision-manufactured in ISO 9001-certified facilities, and are fully RoHS and REACH compliant, ensuring environmental safety and global regulatory alignment. Customization services for plating, materials, and mechanical design are available upon request.
