SMA Jack (Female) Straight Cable Connector for RG-174, RG-188A, RG-316, Belden 7805, DC-6GHz
Key Specifications
Type Design:
Standard
Body Style:
Straight
Impedance (Ohm):
50
Frequency, Max (GHz):
6.0
Connector Style:
Cable Connector
Connector Series:
SMA
Connector Gender:
Jack (Female)
Connection Method:
Threaded (Screw-lock)
Center Contact:
Crimped or Soldered
Cable Entry:
Crimped
Mount Method:
None
Body Material:
Brass
Body Plating:
Copper-Tin Zinc Alloy
Captivated Type:
Mechanical Captivation
Suitable Cables:
RG-316(316/U)
Description
SMA Jack (Female) | Crimped Cable Entry | Screw-lock | Brass Body
The ROSNOL SMA2C50-G316A/94 is a straight cable jack optimized for RF applications up to 6 GHz. It features a screw-lock coupling mechanism and a soldered or crimped centre contact, with a crimped cable entry suitable for RG 174, RG 188A, RG 316, and BELDEN-7805 cables.The connector body and crimp ferrules are made of brass with copper-tin-zinc alloy plating. The centre contact is gold-plated beryllium copper (nickel underplated), and the insulator is PTFE, offering high reliability and thermal stability.
ROSNOL’s precision-engineered RF connectors offer a competitive alternative to products from leading manufacturers in Europe, the USA, and other global markets. All Rosnol RF components are precision-manufactured in ISO 9001-certified facilities, and are fully RoHS and REACH compliant, ensuring environmental safety and global regulatory alignment. Customization services for plating, materials, and mechanical design are available upon request.
