Key Specifications
Description
FME Plug (Male) Straight Cable Connector for RG 316 cable, DC to 2.5 GHz, 50 Ω, with crimped cable entry.
The ROSNOL FME1C50-G316A/13 is a straight cable Plug (Male) designed for RG174, RG188A, RG316, and BELDEN 7805 cables. It features a 50 Ω impedance and supports frequencies from DC to 2.5 GHz. The connector utilizes a screw-lock coupling mechanism, with a crimped cable entry and a center contact that can be either crimped or soldered. Engineered for reliable RF performance, it operates within a temperature range of -65°C to +165°C.
This connector is constructed with a brass body and center contact. The center contact is gold-plated over a nickel underplate, while the body and crimp ferrules are nickel-plated brass. The insulator is made of PTFE for optimal dielectric stability. Crimp dimensions include a 3.25 mm HEX ferrule and a 0.7 mm SQ center contact, ensuring secure termination and signal integrity.
ROSNOL’s precision-engineered RF connectors offer a competitive alternative to products from leading manufacturers in Europe, the USA, and other global markets. All Rosnol RF components are precision-manufactured in ISO 9001-certified facilities, and are fully RoHS and REACH compliant, ensuring environmental safety and global regulatory alignment. Customization services for plating, materials, and mechanical design are available upon request.
