SMC Plug (Male) Straight Cable connector for RG-58, RG-58A, RG-58C, RG-141, RG-303, BELDEN 7806A, BELDEN 9907, LMR-195, RNL-195, DC-6GHz VSWR1.22
Key Specifications
Type Design:
Standard
Body Style:
Straight
Impedance (Ohm):
50
Frequency, Max (GHz):
6.0
VSWR, Max:
1.22
Connector Style:
Cable Connector
Connector Series:
SMC
Connector Gender:
Plug (Male)
Connection Method:
Threaded (Screw-lock)
Center Contact:
Crimped or Soldered
Cable Entry:
Crimped
Mount Method:
None
Body Material:
Brass
Body Plating:
Copper-Tin Zinc Alloy
Captivated Type:
Mechanical Captivation
Suitable Cables:
RG-58(58/U)
Description
SMC Plug (Male) | Crimped Cable Entry | Screw-lock | Brass Body
The ROSNOL SMC1C50-G058A/H44 is a straight SMC plug (male) designed for robust RF signal transmission up to 6 GHz, with a 50 Ω impedance. This connector achieves a maximum VSWR of 1.22 (≥20.08 dB return loss) and an insertion loss of ≤0.05 dB, ensuring excellent signal integrity. The screw-lock coupling mechanism provides secure and stable mating, while the centre contact supports soldered or crimped termination and the cable entry is optimized for crimped assembly.Key components are made from phosphor bronze and brass with copper-tin-zinc alloy or gold plating (nickel underplated), including the centre contact, body, coupling nut, and crimp ferrules. The insulator is PTFE for superior dielectric properties. This connector is compatible with RG 58, RG 58A, RG 58C, RG 141, RG 303, BELDEN-7806A, BELDEN-9907, Times LMR 195, and ROSNOL RNL 195 cables.
ROSNOL’s precision-engineered RF connectors offer a competitive alternative to products from leading manufacturers in Europe, the USA, and other global markets. All Rosnol RF components are precision-manufactured in ISO 9001-certified facilities, and are fully RoHS and REACH compliant, ensuring environmental safety and global regulatory alignment. Customization services for plating, materials, and mechanical design are available upon request.
