FME Jack (Female) Right-Angle Cable Connector for RG-58C, RG-303, LMR-195, RNL-195, DC -2.5 GHz
Key Specifications
Type Design:
Standard
Body Style:
Right Angle
Impedance (Ohm):
50
Frequency, Max (GHz):
2.5
Connector Style:
Cable Connector
Connector Series:
FME
Connector Gender:
Jack (Female)
Connection Method:
Threaded (Screw-lock)
Center Contact:
Soldered
Cable Entry:
Crimped
Mount Method:
None
Body Material:
Brass
Body Plating:
Copper-Tin Zinc Alloy
Captivated Type:
Mechanical Captivation
Suitable Cables:
RG-58C
Description
FME Jack (Female) | Crimped Cable Entry | Screw-lock | Brass Body
The ROSNOL FME2C59-G058A/H4 is a right-angle cable jack (female) RF connector optimized for 50-ohm transmission lines from DC to 2.5 GHz. It employs a screw-lock coupling mechanism and a soldered center contact configuration. The crimped cable entry ensures reliable strain relief and stable signal performance with RG 58C, RG 303, Times LMR 195, and RNL 195 cables.The connector body and crimp ferrules are made of brass with Copper-Tin-Zinc alloy plating, offering excellent mechanical strength and corrosion resistance. The center contact is fabricated from brass with gold plating over a nickel underlayer, and the insulator is PTFE for superior dielectric performance. Recommended crimp dimensions include 5.41 mm [.213 inch] HEX for the ferrule.
ROSNOL’s precision-engineered RF connectors offer a competitive alternative to products from leading manufacturers in Europe, the USA, and other global markets. All Rosnol RF components are precision-manufactured in ISO 9001-certified facilities, and are fully RoHS and REACH compliant, ensuring environmental safety and global regulatory alignment. Customization services for plating, materials, and mechanical design are available upon request.
