FME Plug (Male) Straight Cable Connector for RG-58, RG-58A, RG-58C, RG-141, RG-303, BELDEN 7806A, BELDEN 9907, LMR 195, DC -2.5 GHz
Key Specifications
Type Design:
Standard
Body Style:
Straight
Impedance (Ohm):
50
Frequency, Max (GHz):
2.5
Connector Style:
Cable Connector
Connector Series:
FME
Connector Gender:
Plug (Male)
Connection Method:
Threaded (Screw-lock)
Center Contact:
Crimped or Soldered
Cable Entry:
Crimped
Mount Method:
None
Body Material:
Brass
Body Plating:
Nickel
Captivated Type:
Mechanical Captivation
Suitable Cables:
RG-58(58/U)
Description
FME Plug (Male) | Crimped Cable Entry | Screw-lock | Brass Body
The ROSNOL FME1C50-G058A/13 is a 50 Ω RF Plug (Male) connector designed for screw-lock coupling and crimped cable termination. It supports frequencies from DC to 2.5 GHz and is compatible with RG58, RG141, RG303, BELDEN 7806A, and LMR 195 cables. The center contact can be soldered or crimped, and the connector is rated for operation from −65°C to +165°C.The connector body and crimp ferrule are machined from brass and plated with nickel for corrosion resistance. The center contact is brass with gold plating over a nickel underlayer. The insulator is made of PTFE, ensuring excellent dielectric stability. Crimp dimensions are 5.41 mm for the ferrule and 1.73 mm for the center contact.
ROSNOL’s precision-engineered RF connectors offer a competitive alternative to products from leading manufacturers in Europe, the USA, and other global markets. All Rosnol RF components are precision-manufactured in ISO 9001-certified facilities, and are fully RoHS and REACH compliant, ensuring environmental safety and global regulatory alignment. Customization services for plating, materials, and mechanical design are available upon request.
