1.6-5.6 Cable Connector | Bulkhead | HUAWEI E1
Based on the provided document, here is a product description for the 75 Ohm 1.6/5.6 Jack (Female) Bulkhead Mount Connector.
This technical data sheet describes the ROSNOL 16562CA70-E1A/H3, a versatile 75 Ohm 1.6/5.6 Jack (Female) Bulkhead Mount connector. The connector features a solder center contact and a crimp cable entry, making it suitable for Huawei El cables. All dimensions are in millimeters and inches. The connector's robust design can withstand a temperature range from -65°C to +165°C. Its piece parts are made from high-quality materials, including a gold-plated phosphor bronze center contact, and a nickel-plated brass body and crimp ferrules. The insulator is made of PTFE. It is designed for a minimum of 500 mating cycles.
A key feature of this connector is its unique coupling mechanisms, which support Screw-lock, Snap-on, and Slide-in connections. This versatility allows the connector to be used in various applications, offering installation flexibility and reliable signal integrity. The connector is RoHS compliant, ensuring environmental safety and alignment with global regulations. The electrical data indicates an impedance of 75Ω, with limitations possible due to the cable type and manufacturing process.
ROSNOL’s precision-engineered RF connectors offer a competitive alternative to products from leading manufacturers in Europe, the USA, and other global markets. All Rosnol RF components are precision-manufactured in ISO 9001-certified facilities, and are fully RoHS and REACH compliant, ensuring environmental safety and global regulatory alignment. Customization services for plating, materials, and mechanical design are available upon request.
