SMA Plug (Male) Termination Load, DC-18GHz 1W VSWR 1.2

SMA Plug (Male) Termination Load | DC to 18 GHz | 50 Ω | 1 W

The T-A15-18G1WA/9XX is a high-performance coaxial termination designed for precision RF and microwave applications. This load operates across a broad frequency range from DC to 18 GHz with a nominal impedance of 50 Ω. It maintains excellent signal integrity with a VSWR of 1.2 or less. Engineered for durability, the unit features a screw-lock coupling mechanism and is rated for a minimum of 500 mating cycles. Mechanical specifications include a center contact captivation of ≥ 20 N and a recommended operating torque between 0.8 Nm and 1.1 Nm. The device manages power effectively with a 1 Watt average rating at 25°C.

Quality construction is evident in the material selection and plating processes. The center contact is fabricated from Beryllium Copper with gold plating over a non-magnetic nickel-phosphorus underplate to ensure superior conductivity. Both the main body and the coupling nut are constructed from passivated stainless steel. The internal insulator is made of high-grade PTFE, supplemented by a silicone rubber gasket. This component is ideal for use in telecommunications infrastructure and laboratory testing where precision signal termination is critical for protecting sensitive equipment.

As a product from ROSNOL, an ISO 9001 certified manufacturer, this termination meets the highest standards of production quality and consistency. The unit is fully RoHS compliant, ensuring adherence to international environmental safety regulations. ROSNOL products offer a high-quality, cost-effective alternative to major European and American brands, providing equivalent performance at a more competitive price point. In addition to our standard catalog items, we offer comprehensive customization services to meet specific project requirements.
