N Plug (Male) Termination Load With Chain, DC-12.4GHz 2W VSWR 1.15

N Type Termination Load Plug (Male) with Chain | DC to 12.4 GHz | 50 Ω | 2 W

The ROSNOL T-N15-12.4G2WA-70/9XX is an N Type termination load plug with integrated safety chain, designed for broadband RF systems operating from DC to 12.4 GHz. It provides a nominal impedance of 50 Ω with a maximum VSWR of ≤ 1.15 (Return Loss ≥ 23.13 dB), ensuring excellent impedance matching and minimal signal reflection. Rated for an average power handling of 2 W at 25°C, this termination load is suitable for terminating RF ports in telecommunications equipment, wireless infrastructure, RF test systems, and field maintenance applications, where secure attachment and ease of handling are required.

The center contact is manufactured from beryllium copper with gold plating over a non-magnetic nickel–phosphorus underlayer to ensure high conductivity and mechanical resilience. The connector body and coupling nut are made of stainless steel with passivated surface treatment, providing superior corrosion resistance and durability in harsh or outdoor environments. A PTFE insulator maintains stable dielectric performance across the operating frequency range, while a silicone rubber gasket supports reliable environmental sealing. The stainless steel safety chain with passivated finish enhances retention during installation and servicing.

ROSNOL RF termination loads are manufactured under ISO 9001-certified quality management systems and comply with RoHS and REACH regulations. Delivering reliable RF performance, robust mechanical construction, and competitive pricing, ROSNOL termination loads offer a cost-effective alternative to products from leading European and American brands. Customization services for materials, plating, frequency range, and mechanical features are available to support specific RF and microwave system requirements.
