N Type Termination Load Plug (Male) | DC to 10 GHz | 50 Ω | 25 W

The ROSNOL T-N15-10G25WA/144 is a high-power N Type termination load plug developed for RF and microwave systems requiring reliable broadband signal absorption with enhanced power handling. Operating from DC to 10 GHz, it provides a nominal impedance of 50 Ω with a maximum VSWR of ≤ 1.25 (Return Loss ≥ 19.1 dB). Rated for 25 W average power handling at 25°C, this termination load is suitable for terminating high-power RF outputs, protecting transmitters, and supporting system testing in demanding RF environments. The screw-lock coupling mechanism ensures secure and stable installation in professional RF systems, telecommunications equipment, and test setups.

The center contact is made from brass with gold plating over a nickel underlayer to ensure low contact resistance and stable electrical performance under high-power operation. The connector body is constructed from brass with a copper–tin–zinc alloy finish, providing mechanical robustness and corrosion resistance. A PTFE insulator maintains reliable dielectric performance, while the integrated heat sink is manufactured from aluminum with black anodized plating to enhance thermal dissipation during continuous power operation. The mechanical structure supports efficient heat management and long-term reliability in high-power RF applications.

ROSNOL high-power RF termination loads are manufactured in ISO 9001-certified facilities and fully comply with RoHS and REACH regulations. Offering dependable RF performance, strong thermal management, and competitive pricing, ROSNOL products provide a cost-effective alternative to established European and American RF component brands. Flexible customization services, including power handling, materials, plating, and mechanical design options, are available to meet specific RF and microwave system requirements.
