Key Specifications
Type Design:
Precision
Impedance (Ohm):
50
Frequency, Max (GHz):
40
VSWR, Max:
1.15
Power, Max (Watts):
1
Connector Series:
2.92mm
Connector Gender:
Plug (Male)
Connection Method:
Threaded (Screw-lock)
Body Material:
Stainless Steel
Body Plating:
Passivated
Description
2.92 mm Plug (Male) Termination Load with Chain | DC to 40 GHz | 1 W | Stainless Steel Body
The ROSNOL T-K15-40G1WA-100/9XX 2.92 mm plug (male) termination load with chain is designed to provide precise 50 ohm impedance matching for broadband RF and microwave systems. Supporting a frequency range from DC to 40 GHz, this termination load maintains a maximum VSWR of 1.15, ensuring effective signal absorption and reduced reflections across the operating band. Rated for 1 watt of continuous power handling, it is suitable for RF testing, calibration, and unused port termination in environments requiring secure component retention.This termination load features a screw-lock coupling mechanism and is mechanically compatible with SMA and 3.5 mm interfaces. The integrated stainless steel chain provides mechanical retention, while a passivated stainless steel body, gold-plated beryllium copper center contact, and PS insulator support stable electrical performance across an operating temperature range from -55 C to +125 C.
ROSNOL termination loads deliver stable performance and consistent quality at competitive pricing, offering a reliable alternative to products from leading European and American manufacturers. All ROSNOL RF components are produced under ISO 9001-certified manufacturing processes and fully comply with RoHS and REACH requirements. Customization services for mechanical design, materials, and plating options are available to meet specialized RF and microwave system requirements.
