Key Specifications
Type Design:
Precision
Impedance (Ohm):
50
Frequency, Max (GHz):
50
VSWR, Max:
1.20
Power, Max (Watts):
1
Connector Series:
2.4mm
Connector Gender:
Plug (Male)
Connection Method:
Threaded (Screw-lock)
Body Material:
Stainless Steel
Body Plating:
Passivated
Description
The T-Q15-50G1WA/9XX is a 2.4mm male coaxial 1 watt termination. This RF load termination design has an impedance of 50 Ohm and is fully compliant to RF industry standards. The 1 watt 2.4mm maletermination has a straight body configuration.
The T-Q15-50G1WA/9XX dummy load has a beryllium copper pin with gold plating(nickel underplated) and a brass body with passivated plating. Similar to almost all of our countless other millimeter wave, microwave and RF components, our 2.4mm plug coax terminator is in full compliance with RoHS (Directive 2011/65/EU) and REACH (EC 1907/2006).
Rosnol's T-Q15-50G1WA/9XX male 2.4mm RF termination has a maximum frequency of 50 GHz and a max. VSWR of 1.20 or min. Return Loss of 20.8 dB. As a result, this high-quality termination is a good alternative to the interconnect product choices from competitors from Europe, the USA, or other markets.
Rosnol's millimeter wave, microwave and radio frequency products are precision manufactured in and shipped from its ISO certified (ISO9001:2015) factory. Customization (material, plating, body, etc.) is possible upon request.
The T-Q15-50G1WA/9XX dummy load has a beryllium copper pin with gold plating(nickel underplated) and a brass body with passivated plating. Similar to almost all of our countless other millimeter wave, microwave and RF components, our 2.4mm plug coax terminator is in full compliance with RoHS (Directive 2011/65/EU) and REACH (EC 1907/2006).
Rosnol's T-Q15-50G1WA/9XX male 2.4mm RF termination has a maximum frequency of 50 GHz and a max. VSWR of 1.20 or min. Return Loss of 20.8 dB. As a result, this high-quality termination is a good alternative to the interconnect product choices from competitors from Europe, the USA, or other markets.
Rosnol's millimeter wave, microwave and radio frequency products are precision manufactured in and shipped from its ISO certified (ISO9001:2015) factory. Customization (material, plating, body, etc.) is possible upon request.
