Key Specifications
Type Design:
Precision
Body Style:
Straight
Impedance (Ohm):
50
Frequency, Max (GHz):
40
VSWR, Max:
1.25
Connector Series:
2.92mm
Connector Gender:
Jack (Female)
Connection Method:
Threaded (Screw-lock)
Center Contact:
Soldered
Mount Method:
None
Body Material:
Stainless Steel
Body Plating:
Passivated
Captivated Type:
Mechanical Captivation
Bankend Type:
Coaxial End
Description
2.92mm PCB Connector | End Launch | Stainless Steel Body
The ROSNOL K2HA50-1892D/9X is a 2.92mm female connector designed for PCB end-launch mounting. It features a screw-lock coupling mechanism rated for ≥500 mating cycles and axial contact captivation ≥20N. Operating from DC to 40GHz with 50Ω impedance, it ensures high-frequency signal integrity.Constructed with gold-plated beryllium copper contacts and a stainless steel body, the connector includes a nickel-plated brass transition block and PTFE insulation. Launch pin is also gold-plated for optimal conductivity.
ROSNOL’s precision-engineered RF connectors offer a competitive alternative to products from leading manufacturers in Europe, the USA, and other global markets. All Rosnol RF components are precision-manufactured in ISO 9001-certified facilities, and are fully RoHS and REACH compliant, ensuring environmental safety and global regulatory alignment. Customization services for plating, materials, and mechanical design are available upon request.
