SMA Female Connector, 2 Hole Flange Mount, Flat Terminal, 12.22 mm Hole Spacing, 50 Ω, DC-18 GHz VSWR ≤1.30.
ROSNOL SMA2GTD50-1200A/91 is a high-performance SMA Jack (Female) connector engineered for RF and microwave applications requiring reliable panel-mounted connectivity. This 50 Ohm connector features a solder attachment interface, 2-hole flange mount design, and flat terminal configuration with 12.22 mm (0.481 inch) hole spacing. Operating from DC to 18 GHz, it provides a VSWR of ≤ 1.30 and insertion loss of ≤ 0.05 × √F (GHz) dB, helping maintain signal integrity in demanding RF systems. Electrical performance also includes insulation resistance of ≥ 5 GΩ, center contact resistance of ≤ 3 mΩ, outer contact resistance of ≤ 2 mΩ, and power handling capability up to 200 W at 2 GHz.
The connector features a beryllium copper center contact with gold plating over nickel underplating for excellent conductivity and mating reliability. The body is constructed from brass with gold plating and nickel underplating, while the PTFE insulator provides dependable dielectric stability. A screw-lock coupling mechanism ensures secure mating, while the soldered center contact and flat terminal design support robust mechanical performance. The connector is rated for a minimum of 500 mating cycles and an operating temperature range from -65°C to +165°C.
This SMA Jack (Female) connector is suitable for wireless communication equipment, microwave modules, antenna systems, RF instrumentation, laboratory testing platforms, and signal routing assemblies. Its gold-plated conductive surfaces, durable flange-mount construction, and dependable electrical characteristics provide a reliable RF interconnect solution for professional applications.
