SC Female Connector, 4 Hole Flange, 11 GHz

Order No:SC2GFA50-3711A/84
Add Cart

Key Specifications

Type Design:
Standard
Impedance (Ohm):
50
Body Style:
Straight
Frequency, Max (GHz):
11
VSWR, Max:
N/A
Connector Series:
SC
Connector Gender:
Jack (Female)
Connection Method:
Threaded (Screw-lock)
Center Contact:
Soldered
Mount Method:
4 Hole Flange
Body Material:
Brass
Body Plating:
Copper-Tin Zinc Alloy
Captivated Type:
Mechanical Captivation
Bankend Type:
Coaxial End

Description

SC Female Connector, 4 Hole Flange Mount, Coaxial End, 18.24 mm Hole Spacing, 50 Ω, DC-11 GHz.

The ROSNOL SC2GFA50-3711A/84 is a high-performance SC straight panel receptacle jack engineered for reliable microwave and RF signal transmission. Featuring a 4-hole flange mount design with an 18.24 mm (0.718 inch) hole spacing and a coaxial terminal, this precision component operates efficiently from DC to 11 GHz. It maintains a characteristic impedance of 50 ohms, ensuring excellent signal integrity and dependable broadband performance across complex communication systems.

Constructed with a durable brass body featuring copper-tin-zinc alloy plating and a beryllium copper center contact with silver plating, the connector provides superior electrical conductivity. A robust PTFE insulator maintains electrical stability, while the screw-lock coupling mechanism ensures secure engagement. Designed for harsh environments, it operates reliably within a wide temperature range of -65°C to +165°C, delivering exceptional mechanical and environmental resilience.

This SC jack (female) is ideal for integration into microwave test equipment, base station infrastructure, phased array radar systems, and high-frequency communication payloads. It delivers exceptional mechanical robustness and electrical reliability for demanding aerospace, defense, and telecommunication applications.
