Key Specifications
Description
N Female Connector, 4 Hole Flange Mount, Solder cup Terminal, 18.25 mm Hole Spacing, 50 Ω, DC-11 GHz, VSWR ≤1.20.
ROSNOL N2GFB50-2500C/9Y is a high-performance N Jack (Female) connector engineered for RF and microwave applications that require secure flange mounting and efficient signal transmission. The connector features a 4-hole flange mount configuration with 18.25 mm (0.719 inch) hole spacing and a solder cup terminal, providing reliable cable attachment and mechanical stability. Designed with a 50 Ω impedance and operating from DC to 11 GHz, it delivers VSWR ≤ 1.20 and insertion loss ≤ 0.1 × √F (GHz) dB, supporting low-loss RF performance across a broad frequency spectrum.
The center contact is fabricated from beryllium copper and plated with gold over a non-magnetic nickel-phosphorus underplating to ensure excellent conductivity and long-term contact durability. Its stainless-steel body with nickel plating enhances resistance to corrosion and environmental wear. A PTFE insulator maintains stable dielectric characteristics, while the solder cup center conductor supports dependable solder termination for cable integration. The screw-lock coupling mechanism supports at least 500 mating cycles and is designed for operation from -55°C to +155°C.
This N-type connector is ideal for wireless communication systems, RF test equipment, antenna feed assemblies, microwave modules, measurement instruments, and industrial RF applications. Its combination of robust materials and reliable electrical performance helps maintain signal integrity in demanding RF environments.
