Key Specifications
Type Design:
Standard
Connection Type:
In-Series
Connector 1 Series:
QMA
Connector 1 Gender:
Jack (Female)
Connector 2 Series:
QMA
Connector 2 Gender:
Plug (Male)
Body Style:
Straight
Impedance (Ohm):
50
Connector 1 Connection Method:
Threaded (Screw-lock)
Connector 2 Connection Method:
Threaded (Screw-lock)
Frequency, Max (GHz):
3.0
Connector 1 Body Material:
Brass
Connector 1 Body Plating:
Copper-Tin-Zinc Alloy
Connector 2 Body Material:
Brass
Connector 2 Body Plating:
Copper-Tin-Zinc Alloy
VSWR, Max:
1.25
Power, Max (Watts):
2
Attenuation Max. (dB):
10
Description
The FA-QA1QA25A-3G2W10/944-94 is a QMA male to QMA female fixed coaxial attenuator. This resistive Pi 3,6,10,20,30 dB attenuator has an attenuator pad design. The FA-QA1QA25A-3G2W10/944-94 fixed attenuator has an impedance of 50 Ohm and is fully compliant to RF industry standards. It has a straight body configuration made of Brass with Copper-Tin-Zinc Alloy plating.
Similar to almost all of our countless other millimeter wave, microwave and RF components, our to QMA plug to QMA jack coaxial fixed attenuator is in full compliance with RoHS (Directive 2011/65/EU) and REACH (EC 1907/2006).
Rosnol’s FA-QA1QA25A-3G2W10/944-94 QMA male to QMA female fixed RF attenuator has a maximum frequency of 3 GHz and a max. VSWR of 1.25 or min. Return Loss of 19.08 dB. As a result, this high-quality attenuator is a good alternative to the interconnect product choices from competitors from Europe, the USA, or other markets.
Rosnol’s millimeter wave, microwave and radio frequency products are precision manufactured in and shipped from its ISO certified (ISO9001:2015) factory. Customization (material, plating, body, etc.) is possible upon request.
Similar to almost all of our countless other millimeter wave, microwave and RF components, our to QMA plug to QMA jack coaxial fixed attenuator is in full compliance with RoHS (Directive 2011/65/EU) and REACH (EC 1907/2006).
Rosnol’s FA-QA1QA25A-3G2W10/944-94 QMA male to QMA female fixed RF attenuator has a maximum frequency of 3 GHz and a max. VSWR of 1.25 or min. Return Loss of 19.08 dB. As a result, this high-quality attenuator is a good alternative to the interconnect product choices from competitors from Europe, the USA, or other markets.
Rosnol’s millimeter wave, microwave and radio frequency products are precision manufactured in and shipped from its ISO certified (ISO9001:2015) factory. Customization (material, plating, body, etc.) is possible upon request.
