Key Specifications
Type Design:
Precision
Connection Type:
In-Series
Connector 1 Series:
2.92mm
Connector 1 Gender:
Jack (Female)
Connector 2 Series:
2.92mm
Connector 2 Gender:
Plug (Male)
Body Style:
Straight
Impedance (Ohm):
50
Connector 1 Connection Method:
Threaded (Screw-lock)
Connector 2 Connection Method:
Threaded (Screw-lock)
Frequency, Max (GHz):
40
Connector 1 Body Material:
Stainless Steel
Connector 1 Body Plating:
Nickel
Connector 2 Body Material:
Stainless Steel
Connector 2 Body Plating:
Passivated
VSWR, Max:
1.40
Power, Max (Watts):
1
Description
The FA-K1K25A-40G1W6/9XX-9X is a 2.92mm male to 2.92mm female fixed coaxial attenuator. This resistive Pi 3,6,10,20,30 attenuator has an attenuator pad design. The FA-K1K25A-40G1W6/9XX-9X fixed attenuator has an impedance of 50 Ohm and is fully compliant to RF industry standards. It has a straight body configuration made of Beryllium Copper with Gold plating(Nickel underplated) plating.
Similar to almost all of our countless other millimeter wave, microwave and RF components, our 2.92mm plug to 2.92mm jack coaxial fixed attenuator is in full compliance with RoHS (Directive 2011/65/EU) and REACH (EC 1907/2006).
Rosnol’s FA-K1K25A-40G1W6/9XX-9X 2.92mm male to 2.92mm female fixed RF attenuator has a maximum frequency of 40 GHz and a max. VSWR of 1.40 GHz or min. Return Loss of 15.56 dB. As a result, this high-quality attenuator is a good alternative to the interconnect product choices from competitors from Europe, the USA, or other markets.
Rosnol’s millimeter wave, microwave and radio frequency products are precision manufactured in and shipped from its ISO certified (ISO9001:2015) factory. Customization (material, plating, body, etc.) is possible upon request.
Similar to almost all of our countless other millimeter wave, microwave and RF components, our 2.92mm plug to 2.92mm jack coaxial fixed attenuator is in full compliance with RoHS (Directive 2011/65/EU) and REACH (EC 1907/2006).
Rosnol’s FA-K1K25A-40G1W6/9XX-9X 2.92mm male to 2.92mm female fixed RF attenuator has a maximum frequency of 40 GHz and a max. VSWR of 1.40 GHz or min. Return Loss of 15.56 dB. As a result, this high-quality attenuator is a good alternative to the interconnect product choices from competitors from Europe, the USA, or other markets.
Rosnol’s millimeter wave, microwave and radio frequency products are precision manufactured in and shipped from its ISO certified (ISO9001:2015) factory. Customization (material, plating, body, etc.) is possible upon request.
