Key Specifications
Type Design:
Precision
Impedance (Ohm):
50
Frequency, Max (GHz):
44
Input Connector Series:
2.4mm
Input Connector Gender:
Jack (Female)
Output Connector Series:
2.4mm
Output Connector Gender:
Jack (Female)
Input VSWR, Max:
1.7
Output VSWR, Max:
1.6
Insertion Loss, Max (dB):
1.3
Description
2.4mm Power Divider | 2-Way | RPC2.4 Jack Interface
The ROSNOL PD2-Q2-12.5-44G_A is a precision-engineered 2-way power divider designed for RF and microwave systems operating from DC to 44 GHz. Featuring RPC2.4 jack connectors and 50 Ω impedance, this compact unit ensures low insertion loss (≤ 1.3 dB), excellent amplitude balance (≤ 0.4 dB), and phase balance (≤ 5°), delivering stable and accurate signal distribution across high-frequency applications.Built with a rugged black-painted housing, the PD2-Q2-12.5-44G_A measures 25.4 × 19 × 12.7 mm and weighs 55g, offering a space-efficient solution for lab and system integration. It provides strong isolation (≥ 16 dB), input VSWR ≤ 1.7, and output VSWR ≤ 1.6, minimizing signal reflections and enhancing overall system performance. The device operates reliably in extreme environments, with a temperature range from -55°C to +95°C, and is fully RoHS compliant.
ROSNOL is committed to delivering high-quality RF/microwave interconnect solutions. All products are manufactured under ISO 9001-certified processes and meet global environmental standards including RoHS and REACH. Trust ROSNOL for precision, durability, and performance in every component.
