Key Specifications
Description
SL 3.5mm Male to 3.5mm Female Straight Adapter, DC-26.5 GHz, VSWR ≤ 1.2, 50 Ω Impedance.
ROSNOL AD-SLPC1PC25A/9XX-9X is a precision RF adapter featuring an SL-3.5mm Plug (Male) to 3.5 mm Jack (Female) straight configuration. Designed for 50 Ω systems, it operates from DC to 26.5 GHz with VSWR ≤ 1.20 and low insertion loss, making it suitable for demanding microwave and millimeter-wave applications. The 3.5 mm interface is mechanically compatible with SMA and 2.92 mm connector systems, providing excellent integration flexibility.
The adapter incorporates beryllium copper center contacts, passivated stainless steel bodies and coupling nuts, PEI insulators, and a silicone rubber gasket. Contacts are gold plated over non-magnetic nickel-phosphorus underplating to ensure low contact resistance, superior conductivity, and long-term reliability. Electrical performance includes insulation resistance ≥ 5 GΩ, RF leakage ≥ 100 dB up to 1 GHz, and working voltage up to 335 Vrms.
With screw-lock coupling, mating durability up to 3000 cycles on the SLPC side, and a frequency capability of 26.5 GHz, the AD-SLPC1PC25A/9XX-9X is ideal for RF laboratory testing, microwave instrumentation, aerospace electronics, high-frequency communication systems, and precision measurement applications where low VSWR and signal integrity are critical.
