UHF Male to N Female Adapter, DC-300 MHz

Order No:AD-U1N25A/H44-H4
Add Cart

Key Specifications

Type Design:
Standard
Connection Type:
Between Series
Connector 1 Series:
UHF
Connector 1 Gender:
Plug (Male)
Connector 2 Series:
N
Connector 2 Gender:
Jack (Female)
Impedance (Ohm):
50
Body Style:
Straight
Panel Mount:
None
Connector 1 Connection Method:
Threaded (Screw-lock)
Connector 2 Connection Method:
Threaded (Screw-lock)
Frequency, Max (GHz):
300MHz
Connector 1 Body Material:
Brass
Connector 1 Body Plating:
Copper-Tin-Zinc Alloy
Connector 2 Body Material:
Brass
Connector 2 Body Plating:
Copper-Tin-Zinc Alloy
VSWR, Max:
N/A

Description

UHF male to N female RF adapter, DC-300 MHz, 50 Ohm N interface, copper-tin-zinc plated brass body.

ROSNOL AD-U1N25A/H44-H4 is an RF adapter designed to mate a UHF plug (male) with an N jack (female). The adapter supports operation from DC to 300 MHz and provides an effective transition between UHF and N-type interfaces for RF communication and signal distribution applications.

The design features phosphor bronze center contacts with gold plating over nickel underplating for reliable conductivity and contact stability. The brass body and coupling nut utilize copper-tin-zinc alloy plating to improve durability and environmental resistance, while PTFE insulators ensure consistent dielectric performance. Both connectors employ secure screw-lock coupling mechanisms.

Engineered for dependable RF interconnection, this adapter simplifies integration between legacy UHF equipment and N-type RF systems. Its robust construction and stable electrical characteristics make it suitable for antenna installations, communication networks, RF laboratory equipment, testing platforms, and general-purpose RF infrastructure.
