Key Specifications
Description
BNC Female to UHF Male Straight Adapter, DC-300 MHz, VSWR ≤ 1.20, 50 Ω Impedance.
ROSNOL AD-U1B25A/H44-H4 is a precision RF adapter designed to connect a UHF plug (male) to a BNC jack (female). With a 50 Ohm impedance, DC to 300 MHz operating range, VSWR ≤ 1.20, and low insertion loss, this adapter supports efficient signal transfer in RF communication and electronic measurement systems.
The adapter utilizes phosphor bronze center contacts with gold plating over non-magnetic nickel-phosphorus underplating to optimize conductivity and mating reliability. The brass body and coupling nut are finished with a copper-tin-zinc alloy plating that enhances environmental durability, while PTFE insulation contributes to stable electrical properties and long-term performance.
Combining a screw-lock UHF interface with a bayonet-lock BNC interface, this adapter enables fast and secure interconnection between different RF connector platforms. It is well suited for wireless communication equipment, antenna installations, instrumentation systems, RF development laboratories, and maintenance applications where dependable connectivity and consistent signal performance are required.
