Key Specifications
Description
N Female to TNC Male Straight Adapter, DC-11 GHz, VSWR ≤ 1.2, 50 Ω Impedance.
ROSNOL AD-T1N25A/H33-H3 is a 50 Ω RF adapter engineered to connect a TNC Plug (Male) and an N Jack (Female) interface. Covering frequencies from DC to 11 GHz, the adapter achieves VSWR ≤ 1.20 and low insertion loss, supporting high-quality RF signal transmission in communication systems, antennas, testing equipment, and microwave applications.
Constructed with phosphor bronze center contacts on both connector interfaces, the adapter features gold plating over non-magnetic nickel-phosphorus underplating to enhance conductivity and corrosion resistance. The connector bodies and coupling nut are made from nickel-plated brass, and PTFE dielectric insulators maintain stable electrical characteristics. Important RF parameters include ≥5 GΩ insulation resistance, 500 Vrms working voltage, ≤0.05 × √F dB insertion loss, and power handling up to 80 W at 2 GHz.
Its durable threaded coupling design supports 500 minimum mating cycles and reliable operation from-65°C to +165°C. The AD-T1N25A/H33-H3 is ideal for RF laboratories, wireless communication infrastructure, antenna feed systems, and measurement equipment requiring dependable TNC-to-N connectivity.
