SMA Plug (Male) to UHF Jack (Female) Adapter, DC-300MHz VSWR 1.20

SMA Plug (Male) to UHF Jack (Female) Adapter | Screw-lock | Brass Body

The ROSNOL AD-A1U25A/H33-H3 RF adapter provides dependable performance for low-frequency applications with 50 Ω impedance and DC to 300 MHz operating range. It achieves VSWR ≤1.20 (≥20.83 dB) and insertion loss ≤0.05 × √F (GHz) dB, ensuring stable signal transmission. Additional specifications include insulation resistance ≥5 GΩ, center contact resistance ≤3 mΩ (SMA) and ≤5 mΩ (UHF), and durability with 500 mating cycles. The adapter operates within -65°C to +165°C and features screw-lock coupling for secure engagement.

The SMA side uses phosphor bronze contacts with 3 µinch gold plating over 80 µinch non-magnetic nickel-phosphorus underplating, brass body with nickel finish, PTFE insulator, silicone gasket, and nickel-plated brass coupling nut. The UHF side includes phosphor bronze contacts with identical plating, brass body with nickel finish, and PTFE insulation for corrosion resistance and long-term reliability.

ROSNOL’s precision-engineered RF adapters deliver reliable performance across a wide range of RF and microwave systems. Designed to meet the stringent demands of high-frequency signal transmission, ROSNOL adapters offer a cost-effective alternative to products from leading European and American brands. All ROSNOL RF components are manufactured in ISO 9001-certified facilities and fully comply with RoHS and REACH regulations, ensuring global environmental and safety standards. Customization services for materials, plating, and mechanical design are available to support specialized interconnect requirements.
