Key Specifications
Description
SMA Male to Precision N Male Straight Adapter, DC- 18 GHz, VSWR ≤ 1.15, 50 Ω Impedance.
The ROSNOL AD-A1PCN15B/H11-H44 is a high-performance SMA Plug (Male) to Precision N Plug (Male) straight adapter developed for RF, microwave, and instrumentation applications. Designed for 50 Ω systems, the adapter supports operation from DC to 18 GHz and provides a reliable transition between SMA and Precision N interfaces. Its precision construction and low VSWR performance make it suitable for wireless communications, antenna integration, test equipment, and broadband microwave networks.
The adapter offers a maximum VSWR of 1.15 and low insertion loss characteristics to help maintain signal integrity at high frequencies. Center contacts are manufactured from phosphor bronze with gold plating, while the SMA side body utilizes gold-plated brass construction and the Precision N side features a copper-tin-zinc alloy finish. PTFE insulators and silicone rubber gaskets further enhance durability and long-term electrical reliability.
With screw-on coupling interfaces and support for at least 500 mating cycles, the AD-A1PCN15B/H11-H44 delivers secure and repeatable connections in demanding environments. Its wide operating temperature range from -65°C to +165°C makes it suitable for RF laboratories, communication systems, microwave modules, and general-purpose high-frequency interconnect applications.
