Key Specifications
Type Design:
Standard
Connection Type:
Between Series
Connector 1 Series:
SMA
Connector 1 Gender:
Plug (Male)
Connector 2 Series:
N
Connector 2 Gender:
Plug (Male)
Body Style:
Straight
Impedance (Ohm):
50
Panel Mount:
None
Connector 1 Connection Method:
Threaded (Screw-lock)
Connector 2 Connection Method:
Threaded (Screw-lock)
Frequency, Max (GHz):
12
Connector 1 Body Material:
Brass
Connector 1 Body Plating:
Nickel
Connector 2 Body Material:
Brass
Connector 2 Body Plating:
Nickel
VSWR, Max:
1.15
Description
SMA Plug (Male) to N Plug (Male) RF Adapter | Screw-lock | Brass Body
The ROSNOL AD-A1N15A/H33-H33 RF adapter is designed for high-performance RF connectivity between SMA plug (male) and N plug (male) interfaces. It supports 50 Ω impedance, DC to 12 GHz frequency range, and VSWR ≤ 1.15 (≥23.13 dB return loss). It offers low insertion loss, high insulation resistance, and supports up to 200 W power handling at 2 GHz. RF leakage is ≥100 dB up to 1 GHz.Both SMA and N sides feature phosphor bronze contacts, brass bodies with nickel plating, PTFE insulation, silicone rubber gaskets, and screw-lock coupling mechanisms. The adapter supports ≥500 mating cycles and operates within -5°C to +165°C, meeting MIL-STD-202 standards for thermal shock, vibration, corrosion, and moisture resistance.
ROSNOL’s precision-engineered solutions offer a competitive alternative to products from leading manufacturers in Europe, the USA, and other global markets. All ROSNOL components are manufactured in ISO 9001-certified facilities and fully comply with RoHS and REACH regulations, ensuring environmental safety and global regulatory alignment. Customization services for materials, plating, and mechanical design are available to support specialized requirements across a wide range of RF and microwave applications.
