Key Specifications
Description
SMA Male to BNC Female Straight Adapter, DC-6 GHz, VSWR ≤ 1.2, 50 Ω Impedance.
ROSNOL AD-A1B25A/H33-H3 is a 50 Ω RF adapter designed to connect an SMA Plug (Male) interface to a BNC Jack (Female) interface. Featuring DC to 6 GHz frequency coverage, VSWR ≤ 1.20, low insertion loss, and excellent return loss characteristics, it enables reliable signal transfer for communication, testing, and industrial RF applications.
The adapter incorporates gold-plated phosphor bronze center contacts with non-magnetic nickel-phosphorus underplating for stable electrical performance and low contact resistance. Nickel-plated brass bodies and coupling components provide durability and corrosion resistance, while PTFE insulators and silicone rubber gaskets enhance dielectric stability and environmental reliability.
With SMA screw-lock and BNC bayonet-lock interfaces, this adapter simplifies interconnection between different RF connector systems. Its robust construction and dependable electrical characteristics make it suitable for instrumentation, wireless equipment, RF testing, and general microwave applications up to 6 GHz.
