2.4mm Female to 1.85mm Male Adapter, 50 GHz

Order No:AD-V1Q25A/9XX-9X
Add Cart

Key Specifications

Type Design:
Precision
Connection Type:
Between Series
Connector 1 Series:
2.4mm
Connector 1 Gender:
Jack (Female)
Connector 2 Series:
1.85mm
Connector 2 Gender:
Plug (Male)
Impedance (Ohm):
50
Body Style:
Straight
Panel Mount:
None
Connector 1 Connection Method:
Threaded (Screw-lock)
Connector 2 Connection Method:
Threaded (Screw-lock)
Frequency, Max (GHz):
50
Connector 1 Body Material:
Stainless Steel
Connector 1 Body Plating:
Passivated
Connector 2 Body Material:
Stainless Steel
Connector 2 Body Plating:
Passivated
VSWR, Max:
1.15

Description

2.4mm Female to 1.85mm Male Straight RF Adapter, 50 Ohm, DC-50 GHz, VSWR ≤1.15, Stainless Steel Body.

ROSNOL AD-V1Q25A/9XX-9X is a high-frequency RF adapter designed to connect a 1.85mm plug (male) to a 2.4mm jack (female). Operating from DC to 50 GHz with 50 Ohm impedance, VSWR ≤ 1.15, and low insertion loss, this adapter provides reliable broadband signal transmission for advanced RF and microwave systems.

The adapter incorporates gold-plated brass center contacts, passivated stainless steel bodies, and PEI insulators for dependable electrical and mechanical performance. Silicone rubber gaskets enhance environmental durability, while screw-lock coupling mechanisms provide secure and repeatable interconnections in demanding applications.

This adapter is ideal for RF measurement systems, microwave communication equipment, calibration setups, laboratory instrumentation, and high-frequency test environments. Its precision construction helps maintain signal integrity between 1.85mm and 2.4mm connector platforms.
