Key Specifications
Description
SMA Female to Precision N Male Straight Adapter, DC-18 GHz, VSWR ≤ 1.15, 50 Ω Impedance.
The ROSNOL AD-PCN1A25B/933-91 is a high-performance Precision N male to SMA female straight RF adapter designed for applications requiring low reflection and reliable signal transmission. Covering frequencies from DC to 18 GHz with a 50 Ω impedance and VSWR of 1.15, this adapter is suitable for RF testing, microwave instrumentation, wireless communication systems, and laboratory measurement environments.
This adapter features beryllium copper contacts with gold plating and non-magnetic nickel-phosphorus underplating for dependable conductivity and long-term reliability. The Precision N interface incorporates a nickel-plated brass body, while the SMA interface uses a gold-plated brass body. PTFE insulators help maintain consistent electrical performance. Additional specifications include insulation resistance of at least 5 GΩ, insertion loss of ≤ 0.05 × √F (GHz) dB, RF leakage of at least 90 dB up to 1 GHz, and a working voltage of 480 Vrms.
The screw-on coupling design ensures secure and repeatable connections for demanding RF applications. With support for repeated mating cycles and an operating temperature range from -65°C to +165°C, the AD-PCN1A25B/933-91 is an excellent choice for precision RF interconnect systems, microwave assemblies, and high-frequency measurement applications.
