Key Specifications
Description
Precision TNC Female to Precision N Female Straight Adapter, DC-18 GHz, VSWR ≤ 1.15, 50 Ω Impedance.
ROSNOL AD-PCN2PCT25B/9X-9X is a precision RF straight adapter that converts between a Precision N Jack (Female) and a Precision TNC Jack (Female). Designed with 50 Ω impedance and broadband performance from DC to 18 GHz, it delivers VSWR ≤ 1.15 and low insertion loss, making it ideal for high-frequency test, measurement, and communication systems.
This adapter features beryllium copper center contacts with gold plating over non-magnetic nickel-phosphorus underplating for superior electrical performance and contact reliability. Both connector bodies are manufactured from passivated stainless steel for enhanced mechanical strength and corrosion resistance, while PTFE insulators ensure stable dielectric characteristics. Additional specifications include insulation resistance ≥ 5 GΩ and 500 Vrms working voltage.
Engineered for precision RF interconnections, the adapter offers low return loss, excellent signal integrity, and mating durability of more than 500 cycles. It is well suited for RF laboratories, microwave testing equipment, aerospace electronics, wireless infrastructure, and precision instrumentation requiring accurate high-frequency signal transfer.
