Precision N to 4.1/9.5 Female Adapter, 14 GHz

Order No:AD-PCN2MD25A/9X-94
Add Cart

Key Specifications

Type Design:
Precision
Connection Type:
Between Series
Connector 1 Series:
Precision N
Connector 1 Gender:
Jack (Female)
Connector 2 Series:
4.1/9.5
Connector 2 Gender:
Jack (Female)
Impedance (Ohm):
50
Body Style:
Straight
Panel Mount:
None
Connector 1 Connection Method:
Threaded (Screw-lock)
Connector 2 Connection Method:
Threaded (Screw-lock)
Frequency, Max (GHz):
14
Connector 1 Body Material:
Stainless Steel
Connector 1 Body Plating:
Passivated
Connector 2 Body Material:
Brass
Connector 2 Body Plating:
Copper-Tin-Zinc Alloy
VSWR, Max:
1.13

Description

Precision N Female to 4.1-9.5 Female Straight Adapter, DC-14 GHz VSWR ≤ 1.13, 50 Ω Impedance.

ROSNOL AD-PCN2MD25A/9X-94 is a precision RF straight adapter designed to connect a Precision N Jack (Female) to a 4.1-9.5 Jack (Female) interface. Featuring 50 Ω impedance, DC to 14 GHz operating frequency, and VSWR ≤ 1.13, it delivers low reflection and stable RF transmission for wireless infrastructure, test equipment, and communication systems.

The adapter utilizes beryllium copper center contacts with gold plating over non-magnetic nickel-phosphorus underplating to optimize conductivity and long-term contact reliability. The 4.1-9.5 interface body is manufactured from brass with copper-tin-zinc alloy plating, while the Precision N side adopts passivated stainless steel construction. PTFE insulators ensure stable dielectric performance across a wide operating temperature range.

Designed for demanding RF applications, this adapter offers low insertion loss, high mechanical durability, and secure screw-lock coupling on both interfaces. It is well suited for base station equipment, distributed antenna systems, RF testing environments, and telecom networks where reliable impedance matching and signal integrity are essential.
