Key Specifications
Description
Precision N Male to 2.92mm Female Straight Adapter, DC-18 GHz, VSWR ≤ 1.15, 50 Ω Impedance.
ROSNOL AD-PCN1K25B/9XX-9X is a precision straight RF adapter designed to interface a Precision N Plug (Male) with a 2.92 mm Jack (Female). Operating from DC to 18 GHz with 50 Ω impedance and VSWR ≤ 1.15, this adapter provides low-reflection signal transmission and reliable performance for advanced RF, microwave, and test system applications.
Constructed with beryllium copper center contacts, gold plating, and non-magnetic nickel-phosphorus underplating, the adapter ensures excellent conductivity and contact stability. The connector bodies and coupling nut are manufactured from passivated stainless steel to maximize durability and environmental resistance. PS insulators and silicone rubber sealing components support consistent dielectric characteristics and dependable long-term operation. Key RF parameters include insertion loss ≤ 0.4 × √F (GHz) dB, insulation resistance ≥ 5 GΩ, and RF leakage ≥ 90 dB up to 1 GHz.
This adapter is optimized for precision RF and microwave interconnection where signal integrity and mechanical reliability are critical. Its robust screw-lock design, controlled impedance, and high mating durability make it suitable for RF testing, laboratory instrumentation, communication systems, and precision measurement environments.
