Key Specifications
Type Design:
Standard
Connection Type:
Between Series
Connector 1 Series:
FME
Connector 1 Gender:
Plug (Male)
Connector 2 Series:
UHF
Connector 2 Gender:
Jack (Female)
Impedance (Ohm):
50
Body Style:
Straight
Panel Mount:
None
Connector 1 Connection Method:
Threaded (Screw-lock)
Connector 2 Connection Method:
Threaded (Screw-lock)
Frequency, Max (GHz):
300MHz
Connector 1 Body Material:
Brass
Connector 1 Body Plating:
Copper-Tin-Zinc Alloy
Connector 2 Body Material:
Brass
Connector 2 Body Plating:
Copper-Tin-Zinc Alloy
VSWR, Max:
N/A
Description
FME Plug (Male) to UHF Jack (Female) | Straight Design | Screw-Lock | Brass Body
The ROSNOL AD-E1U25A/14-94 is engineered for DC to 300 MHz applications, delivering stable performance with 50 Ω impedance and excellent electrical integrity. Insulation resistance reaches ≥5 GΩ, and contact resistance remains minimal for both FME and UHF sides. The screw-lock coupling mechanism ensures secure engagement, while mechanical durability supports ≥500 mating cycles on the UHF side and ≥300 on the FME side.Constructed with high-quality materials, the UHF center contact is beryllium copper with gold plating over nickel-phosphorus underplating, while the FME center contact uses brass with identical plating structure. Bodies are brass with copper-tin-zinc alloy finish, complemented by PTFE insulators for dielectric stability. The adapter withstands temperatures from -65°C to +165°C and offers strong corrosion resistance for demanding environments.
ROSNOL combines premium quality with competitive pricing, making these RF components an ideal alternative to leading European and American brands. All products are manufactured under ISO 9001-certified processes and fully comply with RoHS and REACH standards. Customization services for plating, materials, and mechanical design are available to meet specialized interconnect requirements.
