Key Specifications
Type Design:
Standard
Connection Type:
Between Series
Connector 1 Series:
FME
Connector 1 Gender:
Plug (Male)
Connector 2 Series:
TNC
Connector 2 Gender:
Plug (Male)
Impedance (Ohm):
50
Body Style:
Straight
Panel Mount:
None
Connector 1 Connection Method:
Threaded (Screw-lock)
Connector 2 Connection Method:
Threaded (Screw-lock)
Frequency, Max (GHz):
2.5
Connector 1 Body Material:
Brass
Connector 1 Body Plating:
Nickel
Connector 2 Body Material:
Brass
Connector 2 Body Plating:
Nickel
VSWR, Max:
N/A
Description
FME Plug (Male) to TNC Plug (Male) | Straight Design | Screw-Lock | Brass Body
The ROSNOL AD-E1T15A/13-133 is a precision RF adapter for 50 Ω systems, operating from DC to 2.5 GHz with stable electrical performance. It ensures insulation resistance ≥5 GΩ, center contact resistance ≤10 mΩ (FME) and ≤1.5 mΩ (TNC), and outer contact resistance ≤1.5 mΩ (FME) and ≤1 mΩ (TNC). Coupling uses screw-lock on both sides, supporting ≥300 mating cycles (FME) and ≥500 cycles (TNC). Recommended torque for TNC side is 0.46–0.69 N·m.Materials and plating: center contacts are brass with 3 µin gold plating over 80 µin nickel-phosphorus underplating. Bodies and coupling nuts are brass with nickel plating; insulators are PTFE; gaskets are silicone rubber. Rated for −65 °C to +165 °C, this adapter offers excellent corrosion resistance and mechanical durability.
ROSNOL delivers precision-engineered RF adapters for uncompromising performance in high-frequency and microwave applications. Manufactured under ISO 9001-certified processes, fully RoHS and REACH compliant, and offering cost-effective alternatives to leading brands. Customization for materials, plating, and mechanical design is available to meet specialized interconnect requirements.
