Key Specifications
Description
2.4mm Female to SSMA Female Straight Adapter, DC-40 GHz, VSWR ≤ 1.15, 50 Ω Impedance.
ROSNOL AD-Q2SA25A/9X-9X is a high-performance RF adapter featuring 2.4mm female and SSMA female interfaces. Designed for 50Ω applications, it operates from DC to 40GHz and provides VSWR ≤1.15, low insertion loss, and excellent return loss characteristics, supporting precision microwave transmission and measurement requirements.
Manufactured with beryllium copper center contacts and passivated stainless-steel bodies, this adapter employs gold-plated contacts with non-magnetic nickel-phosphorus underplating to maximize conductivity and corrosion resistance. PEI insulators, insulation resistance ≥5GΩ, contact resistance optimization, and RF leakage ≥100dB help ensure dependable electrical performance throughout the operating frequency range.
The AD-Q2SA25A/9X-9X combines precision mechanical construction, compatibility with 1.85mm, 2.92mm, and 3.5mm interfaces, and durability rated for more than 500 mating cycles. It is ideally suited for network analyzers, RF laboratory testing, microwave subsystems, wireless infrastructure development, and other applications requiring stable high-frequency connectivity with minimal signal loss.
