2.4mm to SMA Female Adapter, DC-18 GHz

Order No:AD-Q2A25B/9X-9X
Add Cart

Key Specifications

Type Design:
Precision
Connection Type:
Between Series
Connector 1 Series:
2.4mm
Connector 1 Gender:
Jack (Female)
Connector 2 Series:
SMA
Connector 2 Gender:
Jack (Female)
Impedance (Ohm):
50
Body Style:
Straight
Panel Mount:
None
Connector 1 Connection Method:
Threaded (Screw-lock)
Connector 2 Connection Method:
Threaded (Screw-lock)
Frequency, Max (GHz):
18
Connector 1 Body Material:
Stainless Steel
Connector 1 Body Plating:
Passivated
Connector 2 Body Material:
Stainless Steel
Connector 2 Body Plating:
Passivated
VSWR, Max:
1.15

Description

2.4mm Female to SMA Female Straight Adapter, DC-18 GHz, VSWR ≤ 1.15, 50 Ω Impedance.

ROSNOL AD-Q2A25B/9X-9X is a high-performance RF straight adapter that interfaces a 2.4 mm Jack (Female) with an SMA Jack (Female). Designed for 50 Ω systems, it supports frequencies from DC to 18 GHz with VSWR ≤ 1.15, insertion loss ≤ 0.05 × √F (GHz) dB, and RF leakage ≥ 100 dB up to 1 GHz, ensuring reliable broadband performance and signal integrity.

The adapter features beryllium copper center contacts with gold plating over non-magnetic nickel-phosphorus underplating to provide excellent electrical conductivity and long-term reliability. Both interfaces utilize passivated stainless steel bodies for enhanced corrosion resistance, while the 2.4 mm side employs a PEI insulator and the SMA side uses a PTFE insulator for stable dielectric characteristics. Insulation resistance is rated at ≥ 5 GΩ, and both interfaces support more than 500 mating cycles.

With precision-machined interfaces, secure screw-lock coupling, and excellent return loss performance, this adapter is suitable for RF measurement equipment, microwave communication systems, calibration laboratories, aerospace electronics, and test environments that require accurate and repeatable signal transmission between 2.4 mm and SMA connector platforms.
