Key Specifications
Description
2.4mm Female to 2.4mm Male Mitered Right Angle Adapter, DC-50 GHz, VSWR ≤ 1.35, 50 Ω
The ROSNOL ASL-Q1Q25A/9XX-9X is a precision-engineered 2.4mm mitered right angle adapter optimized for RF systems up to 50 GHz. It features a screw-lock coupling mechanism, ≥500 mating cycles, axial captivation ≥20 N, and torque rating up to 1.65 Nm. Electrical specifications include 50 Ω impedance, VSWR ≤1.35 (≥16.54 dB), insertion loss ≤0.6 dB, RF leakage ≥100 dB up to 1 GHz, and voltage ratings of 500 V rms (test) and 150 V rms (working).
Built with a passivated stainless steel body and coupling nut, the ASL-Q1Q25A/9XX-9X includes beryllium copper center contacts with gold plating and PEI insulators. It is mechanically compatible with 1.85 mm connectors and performs reliably across a temperature range of -55°C to +125°C, meeting IEC standards for environmental durability.
ROSNOL’s precision-engineered solutions offer a competitive alternative to products from leading manufacturers in Europe, the USA, and other global markets. All ROSNOL components are manufactured in ISO 9001-certified facilities and fully comply with RoHS and REACH regulations, ensuring environmental safety and global regulatory alignment. Customization services for materials, plating, and mechanical design are available to support specialized requirements across a wide range of RF and microwave applications.
