Key Specifications
Description
N Female to N Female Bulkhead Adapter, DC-12 GHz, VSWR 1.2, 50 Ω Impedance.
ROSNOL AD-N2N25A-BH/9X-9X is an N Jack (Female) to N Jack (Female) Bulkhead RF Adapter designed for reliable RF interconnection and panel-mount installations. Operating from DC to 12 GHz with 50 Ω impedance and VSWR ≤ 1.20, this RF adapter provides low-loss signal transmission and secure interface conversion for communication, antenna, microwave, and test systems.
The adapter features beryllium copper center contacts with gold plating over a non-magnetic nickel-phosphorus underplating. The connector bodies are manufactured from passivated stainless steel, while the insulators are PTFE. Additional components include nickel-plated brass washers and fastening nuts. Key RF specifications include insertion loss ≤ 0.05 × √F (GHz) dB, insulation resistance ≥ 5 GΩ, center contact resistance ≤ 1 mΩ, working voltage 500 Vrms, power handling up to 1000 W at 1 GHz, and RF leakage ≥ 128 dB up to 1 GHz.
Its bulkhead mounting design allows secure installation through panels or enclosures, while the screw-on N interface supports a minimum of 500 mating cycles. AD-N2N25A-BH/9X-9X is suitable for RF communication systems, wireless infrastructure, antenna networks, microwave assemblies, and laboratory instrumentation requiring stable performance and mechanical durability.
