2.92mm Male to 2.92mm Female Mitered Right Angle Adapter, DC-40 GHz, VSWR 1.25, 50 Ω
ROSNOL ASL-K1K25A/9XX-9X is a high-frequency 2.92 mm Plug (Male) to 2.92 mm Jack (Female) mitered right angle RF adapter designed for demanding microwave and millimeter-wave applications. Operating from DC to 40 GHz with a 50 Ohm impedance and maximum VSWR of 1.25, this adapter provides reliable signal transmission and excellent impedance matching across a wide frequency range. The compact right angle configuration enables efficient integration in densely populated RF assemblies and test setups where space management is critical. It is mechanically compatible with both 3.5 mm and SMA connector interfaces, offering additional flexibility for system integration.
The adapter features a precision-engineered construction using beryllium copper center contacts with gold plating for low contact resistance and stable conductivity. The body and coupling nut are manufactured from stainless steel with passivated surfaces to provide excellent mechanical durability and corrosion resistance. PEI insulators and silicone rubber gasket materials further enhance structural integrity and environmental reliability. Electrical performance includes insertion loss of ≤ 0.1 × √F (GHz) dB, insulation resistance of ≥ 5 GΩ, power handling up to 20 W, and operating voltage of 250 V rms.
Designed for RF test systems, microwave instrumentation, aerospace electronics, communication infrastructure, semiconductor testing, and laboratory measurement environments, this 2.92 mm right angle adapter supports high-frequency interconnections where signal integrity is essential. Its screw-on coupling mechanism, minimum 500 mating cycles, and precision microwave design make it a dependable solution for engineers and system integrators working with high-performance RF and microwave equipment.
