Key Specifications
Type Design:
Precision
Connection Type:
In-Series
Connector 1 Series:
2.92mm
Connector 1 Gender:
Plug (Male)
Connector 2 Series:
2.92mm
Connector 2 Gender:
Plug (Male)
Body Style:
Mitered Right Angle
Impedance (Ohm):
50
Panel Mount:
None
Connector 1 Connection Method:
Threaded (Screw-lock)
Connector 2 Connection Method:
Threaded (Screw-lock)
Frequency, Max (GHz):
40
Connector 1 Body Material:
Stainless Steel
Connector 1 Body Plating:
Passivated
Connector 2 Body Material:
Stainless Steel
Connector 2 Body Plating:
Passivated
VSWR, Max:
1.25
Description
2.92mm Plug (Male) to 2.92mm Plug (Male) | L-Adapter | Passivated Stainless Steel Body
The ROSNOL ASL-K1K15A/9XX-9XX is a high-frequency 2.92mm L-adapter designed for precision signal transmission up to 40 GHz. Featuring a screw-lock coupling mechanism, it supports ≥500 mating cycles, center contact captivation ≥20 N, and torque rating up to 1.7 Nm. Electrical performance includes 50 Ω impedance, VSWR ≤1.25 (≥19.08 dB), insertion loss ≤0.05×√F(GHz) dB, RF leakage ≥100 dB up to 1 GHz, and power handling of 20 W. The adapter is rated for 750 V rms test voltage and 250 V rms working voltage.Constructed with a passivated stainless steel body and coupling nut, the ASL-K1K15A/9XX-9XX features beryllium copper center contacts with gold plating, PEI insulators, and a silicone rubber gasket. It operates reliably across a temperature range of -65°C to +165°C and meets MIL-STD-202 standards for thermal shock, corrosion, vibration, and moisture resistance.
ROSNOL’s precision-engineered solutions offer a competitive alternative to products from leading manufacturers in Europe, the USA, and other global markets. All ROSNOL components are manufactured in ISO 9001-certified facilities and fully comply with RoHS and REACH regulations, ensuring environmental safety and global regulatory alignment. Customization services for materials, plating, and mechanical design are available to support specialized requirements across a wide range of RF and microwave applications.
