Key Specifications
Description
3.5mm Jack (Female) 2 Hole Flange Mount Cable Connector for Semi-flex .047, such as Rosnol RSF 047, DC- 26.5 GHz, VSWR ≤ 1.25, 50 Ω, with Soldered Cable Entry.
The PC2EBT50-0047A/9X 3.5mm Female Straight 2-Hole Panel Cable Jack is a precision 50 Ohm RF connector designed for high-frequency signal transmission in microwave, instrumentation, and communication equipment. Covering frequencies from DC to 26.5 GHz, the connector achieves a VSWR of 1.25 or better, helping maintain dependable signal integrity across demanding RF applications. Its two-hole panel mounting configuration provides stable mechanical installation for equipment integration.
Built with a beryllium copper center contact featuring gold plating over a nickel underplate, the connector offers reliable conductivity and long service life. The passivated stainless steel body delivers excellent durability, while the PEI insulator supports stable electrical performance. The design is compatible with RSF047, RSR047, RSF047 PVC, and RSF047 FEP cable types.
A screw-lock coupling mechanism combined with soldered contact and cable attachment ensures secure connectivity and dependable assembly. Operating from -55°C to +165°C and fully RoHS compliant, the PC2EBT50-0047A/9X is an excellent solution for RF instrumentation, microwave devices, and high-frequency communication systems.
