BNC Plug (Male) to Dual BNC Jack (Female) T Adapter | Bayonet-Lock | Brass Body
The ROSNOL ADT-B1B2B25A/133-H3-H3 is a 50 Ω RF T Adapter featuring one BNC Plug (Male) and two BNC Jack (Female) ports for signal distribution applications. Supporting frequencies from DC to 10 GHz, this adapter delivers reliable RF performance with low contact resistance, insulation resistance of ≥ 5 GΩ, and power handling up to 80 W at 2 GHz. The bayonet-lock coupling mechanism enables quick and secure connection, while the rugged construction supports over 500 mating cycles for long-term operation in demanding RF environments.
The female-side center contacts are fabricated from phosphor bronze, while the male-side center contacts are brass, both finished with gold plating over non-magnetic nickel-phosphorus underplating. The connector bodies and coupling nut are constructed from brass with durable nickel plating, complemented by PTFE insulators and silicone rubber gaskets for enhanced mechanical stability and environmental durability.
ROSNOL’s precision-engineered RF adapters deliver reliable performance across a wide range of RF and microwave systems. Designed to meet the stringent demands of high-frequency signal transmission, ROSNOL adapters offer a cost-effective alternative to products from leading European and American brands. All ROSNOL RF components are manufactured in ISO 9001-certified facilities and fully comply with RoHS and REACH regulations, ensuring global environmental and safety standards. Customization services for materials, plating, and mechanical design are available to support specialized interconnect requirements.
