Key Specifications
Description
2.4mm Fixed Attenuator | 10 dB | 5W | DC–50 GHz
The ROSNOL FA-Q1Q25A-50G5W10/9XX-9X Fixed Attenuator is a precision-engineered RF and microwave component designed for accurate signal level control in ultra-broadband applications. Featuring a 2.4 mm Plug (Male) to 2.4 mm Jack (Female) configuration, this 50 Ω attenuator supports frequencies from DC to 50 GHz while delivering stable attenuation performance across the entire operating range. With 10 dB nominal attenuation, 5 W average power handling, and 100 W peak pulse capability, it is well suited for high-frequency testing, calibration, and signal conditioning applications. The low VSWR of ≤1.40 helps maintain signal integrity and minimize unwanted reflections in advanced RF systems.
Constructed using gold-plated beryllium copper center contacts, passivated stainless steel bodies, and a high-performance PEI dielectric, this attenuator combines excellent conductivity, mechanical stability, and corrosion resistance. The 2.4 mm interface is mechanically compatible with 1.85 mm connectors, providing additional flexibility for microwave and millimeter-wave installations.
Key Features & Benefits:
• DC–50 GHz ultra-broadband frequency coverage
• 10 dB attenuation with ±1.0 dB accuracy
• 5 W average and 100 W peak power handling
• Low VSWR for reliable RF performance
• Compatible with 1.85 mm connector systems
• Durable stainless steel construction and RoHS compliance
Target Industries:
RF and microwave testing, aerospace electronics, defense communication systems, satellite technology, semiconductor characterization, 5G and next-generation wireless development, millimeter-wave research, and advanced laboratory measurement environments.
